BOXER-6639M

Fanless Embedded Box PC with 6th/ 7th Generation Intel® Core™ Desktop Processor and PoE

Features

  • Extreme Computing Power & Graphic Display Capability
  • Desktop Grade Socket Type Processor with Longevity Support
  • DDR4 ECC or Non-ECC SODIMM, Up to 32GB
  • VGA + HDMI x 2 Triple Display, HDMI 4K Display
  • 802.3at GbE PoE x 4 (max. 80W in total)
  • USB 3.0 x 6
  • Intel® Industrial-grade GbE LAN x 3
  • Support BIOS Selectable RS-232/422/485 x 6
  • Easy Access Design
  • Wide Range DC 12~36V Input
  • 34-bit Digital Input and Output

IMBM-H110A

Micro-ATX with Intel® 7th/6th Generation Core™ Processor, DDR4 DRAM, M.2 x 1, USB x 10

Features

  • 7th/6th Gen. Intel® Core™ LGA1151 Processor
  • DDR4 DRAM Support, 2400MHz, Max. 32GB
  • Two Independent Display: HDMI x 2, VGA x 1, DVI-D x 1
  • Dual Intel® Gigabit Ethernet
  • M.2 Slot (M key) x 1
  • USB 3.0 Port x 4, USB 2.0 Port x 6

OMNI-5125-BT

12.1” All-In-One Fanless Touch Panel PC with Intel® J1900 Processor

Features

  • 12.1” (1024 x 768) Color TFT LCD Display
  • Intel® Bay Trail J1900 Processor
  • Project Capacitive Multi-Touch
  • IP65 Front Bezel Design
  • Aluminum Design
  • Fanless Operation
  • VESA 100/ Panel Mount/ Stand Support
  • DC 9~30V With Power Protection

OMNI-5155-BT

15” All-In-One Fanless Touch Panel PC with Intel® Celeron® J1900 Processor

Features

    • 15” (1024 x 768) Color TFT LCD Display
    • Intel® Bay Trail J1900 Processor
    • Project Capacitive Multi-Touch
    • VESA 75/100/Panel Mount Support
    • IP65 Front Bezel Design
    • Aluminum Design
    • Fanless Operation
    • VESA 100/ Panel Mount / Stand Support
    • DC 9~30V With Power Protection

OMNI-5215-SKU

21.5” All-In-One Fanless Touch Panel PC with Intel® SkyLake U Processor

Features

    • 21.5” FHD (1920×1080) Color TFT LCD Display
    • Intel® Skylake i5-6300U/ Celeron® Processor
    • Project Capacitive Multi-Touch
    • IP65 Front Bezel Design
    • Aluminum Design
    • Fanless Opertaion
    • VESA 100/Panel Mount Support
    • DC 9~30V With Power Protection

AEC-6967

Advanced Fanless Embedded Controller with 2nd Generation Intel® Core™ i Series Processor and PCI-Express Expansion

Features

  • 2nd Generation Intel® Core™ i Processor
  • Dual-Channel SODIMM DDR3 1066/1333/1600 Memory, Up to 16 GB (Supports DDR3L in Intel® Core™ i7/i5)
  • Intel® Integrated Graphics Engine Supports Dual View by VGA, DVI, HDMI, LVDS
  • COM x 6 (2.5KV Isolation x 2), 2.5KV solated DIO x 1
  • Mini-Card Slot x 2, CFast™ x 1
  • PCI-Express﹝x4﹞ x 2 or PCI x 2 or PCI x 1 + PCI-Express﹝x4﹞ x 1
  • TPM x 1 (Optional)
  • Wide Temperature Support with Intel® Core™ i7-2610UE Processor
  • AAEON Hi-Safe & Hi-Manager Support

AEC-6977

Fanless Embedded Controller with Intel® QM77 Chipset

Features

  • Intel® Core™ i7-3517UE 1.7GHz ProcessorAEC
  • QM77 Chipset
  • COM x 6 (2.5KV Isolation x 2), 2.5KV Isolated DIO
  • Mini PCIe x 2 & CFast x 1
  • Riser Card: PCI x 2, PCI-E〔x4〕x 2, PCI x 1 and PCI-E〔x4〕x 1
  • Hi Safe and Hi Manager Support
  • TPM Support

AEC-6913

Fanless Embedded Controller with Intel® NM10 Chipset

Features

  • Intel® D2550 1.8GHz Processor
  • Intel® NM10 Chipset
  • COM Module Integrated
  • Isolated DI x 4 & DO x 4 (3KV)
  • Isolated RS-232/RS-422/RS-485 x 2 (3KV)
  • PCI x 2 or PCI-E[x1] x 1
  • SIM Slot x 1
  • Mini-PCIe Mini-Card Slot x 2
  • Fanless Operation (-20°C ~ 75°C) with Airflow

BOXER-6914

Fanless Embedded Computer with Intel® Atom™ Processor D2550, 16 COM Ports, Cableless Design

Features

  • Design for Gateway/ Turnsile Control Automation
  • Powered by COM-CV Rev. B
  • Supports Gigabit Ethernet x 2, USB x 6, COM x 16
  • Supports 30 Channels Programmable Digital I/O
  • Dual Expansion Slots For PCI x 2 or PCI + PCIe

AEC-6950

Fanless Embedded Controller with Intel® QM77 Chipset

Features

  • Intel® Core™ i7-3517UE 1.7GHz Processor
  • QM77 Chipset
  • COM Module Integrated
  • Isolation DI x 4 & DO x 4 (3KV)
  • Isolation RS-232/422/485 x 2 (3KV)
  • PCI x 2 or PCI-E ﹝x1﹞/ PCI-E ﹝x16﹞
  • SIM Slot x 1
  • PCIe Mini-Card Slot x 2
  • Fanless Operation (-20°C ~ 55°C) with Airflow

BOXER-6403WT

Wide temperature Compact Embedded Box PC with Intel® Celeron® Processor SoC

Features

4 Digital Input & 2 Digital Output Support Dry Contact & Wet Contact
HDMI Output
Seamless Communication for WiFi, 4G, GPS, Bluetooth, and ZigBee
Aluminum Extrusion
Operating in -30°C ~ 70°C Environment

BOXER-6403M

Wide Temperature Compact Embedded Box PC with Intel® Celeron® Processor SoC


Features

4 Digital Input & 2 Digital Output Support Dry Contact & Wet Contact
HDMI Output
Seamless Communication for WiFi, 4G, GPS, Bluetooth, and ZigBee
2.5″ HDD/SDD bay x 1
Aluminum Extrusion
Operating in -30°C ~ 70°C Environment

BOXER-6403

Compact Embedded Controller with Intel® Celeron®/ Atom™ Processor SoC

Features

Slim, Palm-sized, Fanless Box: 20mm
4 Digital Input & 2 Digital Output Support Dry Contact & Wet Contact
HDMI Output
Seamless Communication for WiFi, 3G,4G, GPS, Bluetooth, and ZigBee
Aluminum Die Casting Enclosure
Low-Power-Consumption CPU

BOXER-6404WT

Wide temperature Compact Embedded Box PC with LAN x 4, HDMI x 2, Intel® Celeron® J1900/N2807 Processor SoC

Features

Quad GbE LAN Port for Industrial Network Appliance
Dual HDMI Port
USB3.0 Port Connectivity
Easy Access Storage Bay
Operating in -30°C ~ 75°C Environment

BOXER-6404M

Wide Temperature Compact Embedded Box PC with LAN x 4, HDMI x 2, Intel® Celeron® J1900/N2807 Processor SoC

Features

Quad GbE LAN Port for Industrial Network Appliance
2.5″ HDD/SDD bay x 1
Dual HDMI Port
USB3.0 Port Connectivity
Easy Access Storage Bay
Operating in -30°C ~ 75°C Environment

BOXER-6404

Compact Embedded Controller with LAN x 4, HDMI x 2, Intel® Celeron® J1900/N2807 Processor SoC

Features

Slim Boxer Design : 30mm
RJ45 LAN Ports x 4 ; HDMI Ports x 2
Operate in -20 °C ~ 60 °C environment

BOXER-6421

Compact Embedded Box PC with Freescale Cortex-A9 iMX6 1.0 GHz Processor

Features

Freescale Cortex-A9 iMX6 1.0 GHz Processor
Support one DVI-D
Dual 10/100/1000 Base-TX Ports
Embedded Linux/Android V 4.xx Ready
Onboard eMMC 8 GB & DDR3 1 GB
Power Input: 7~24V DC

BOXER-6404U

Compact Embedded Box PC with Intel® Celeron® Processor SoC

Features

Dual GbE LAN Port for Industrial Network Appliance
2.5″ HDD/SDD Bay x 1
USB3.0 Port Connectivity
8 bit Programmable Digital Input/Output
12~24V DC-in Support

TKS-P20-CV01

Din Rail Fanless Embedded Box For PICO-CV01


Features

Intel® Atom™ N2600 Processor 1.6GHz
SODIMM DDR3 800 MHz Memory up to 2 GB
DIN RAIL and Fanless System
Support Mini HDMI and VGA Dual Display
Gigabit Ethernet LAN x 1
USB2.0 x 5, COM x 2, 4-bits Digital I/O
mSATA x 1
DC IN +12 or +7~30V Wide Range DC Input

AEC-6876

Fanless Embedded Controller With Intel® Core™ i7/ i5 /i3 /Celeron® Processor and PCI-Express Expansion

Features

Intel® Core™ i7-2710QE/ i5-2510E/ i3-2330E/ Celeron®-B810 Processor
DDR3 SODIMM x 2, Supports DDR3 1066/1333, Max. 16GB
Intel® QM67 Chipset
Gigabit Ethernet x 2
Intel® Integrated Graphics Engine Supports Dual View by VGA, DVI, HDMI, LVDS
COM x 4
PCI x 2, PCI-Express 〔x4〕 x 1
AAEON’s Hi-Safe & Hi-Manager Support (i5/i7 CPU Only)

AEC-6877

Fanless Embedded Controller with Intel® Core™ i7/i5/Celeron Processor and PCI/PCIe Expansion

Features

Intel® Core™ Intel® i7-3610QE, i5-3610ME/ i7-2710QE, i5-2510E and Celeron® B810 Processor
Intel QM77 Chipset
Three Independent Video Output for DisplayPort™ x 2 + VGA or DVI with 3rd Generation Core™ i Series
USB 3.0 x 4
PCI x 2 or PCI-Express﹝x4﹞ x 1
Power Protection: Over Voltage Protection, Low Voltage Protection, Short Circuit Protection, Surge Protection (1000V DC)
AAEON’s Hi-Safe & Hi-Manager Support (i5/i7 CPU Only)

AEC-6643

Fanless Embedded Controller with Intel® Atom™ D2550 B3 Processor


Features

Onboard Intel® Atom™ D2550 B3 Processor
Intel® GMA 3650 Graphic Engine
Dual Independent Display: VGA, DVI-D
Intel® NM10 Chipset (PCH)
USB 2.0 and SATA 3.0 Gb/s
Easy to Install Mini Card with SIM slot x 1 & Memory & HDD By 4 Screws Only
Compact Size & Low power
Cost-Effective Design
Fanless System Design
AAEON’s Hi-Safe Support

AEC-6646 Rev. B

Embedded Controller with Intel® Core™ i Series Processor

Features

LGA1155 Socket Supports Desktop Intel® Core™ i Series Processor (Max. 55W)
Intel® H61 Chipset
HDMI Video Output x 2
Easy to Install CPU & Memory & HDD By 4 Screws Only
Compact Size
Cost-Effective Design
Fanless System Design

AEC-6612 Rev. B

Embedded Controller with Intel® Atom™ D525 Processor


Features

Intel® Atom™ D525 Processor
Intel ICH8M Chipset
Up to COM x 6, USB x 6
Wide DC power Input
Fanless Operating System
Gigabit Ethernet x 2

AEC-6613

Fanless Embedded Controller with Intel® NM10 Chipset

Features

Intel® Atom™ D2550 Processor
Intel® NM10 Express Chipset
Intel® GMA 3650 Integrated Graphic Engine
COM x 4
USB 2.0 x 4
Gigabit Ethernet x 2
VGA Output
Fanless System Design
DVI-D Output (A3/A4/A3M/A4M)
AAEON’s Hi-Safe Support

BOXER-6614

Fanless Embedded Box PC with Intel® Celeron® J1900 2.0 GHz/ Celeron® N2930 Quad Core 1.83 GHz/Celeron® N2807 Dual Core 1.58 GHz

Features

Intel® Celeron® J1900 2.0 GHz/ N2930 Quad Core 1.83 GHz/ Celeron® N2807 Dual Core 1.58 GHz
Intel® HD Graphics Engine
DDR3L 1333 MHz SODIMM x 1, Memory Max. up to 8 GB
Intel® Gigabit Ethernet x 2
VGA + HDMI Output, Support Dual View/Simultaneous Display
RS-232/422/485 x 2, RS-232 x 2
USB3.0 x 1, USB2.0 x 3
Full Size Mini-Card with SIM Slot x 1
Half Size Mini-Card x 1 for Factory-Install
Compact Size & Low Power
Cost-Effective Design
Fanless System Design
AAEON’s Hi-Safe Support

BOXER-6637

Fanless Embedded Controller with Intel® QM77 Chipset

Features

3rd Generation Intel® Core™ i7-3610QE, Core ™ i5-3610ME Processor
Intel QM77 Chipset
Intel HD Graphics 4000
VGA x 1
Gigabit Ethernet x 2
COM x 4
USB3.0 x 2 USB2.0 x 2
2.5” SATA 6.0 Gb/s Hard Disk Drive Bay
Fanless Operation
AAEON’s Hi-Safe & Hi-Manager Support

BOXER-6638

Fanless Embedded Controller with Intel® Haswell BGA1364 Processors and PCH QM87

Features

4th Generation Intel® Core™ i5/i3 Processor CPU: i5-4400E (2.7 GHz) ﹝37W﹞/ i3-4100E (2.4 GHz) ﹝37W﹞
COM Port x 3, USB 3.0 x 2 , USB 2.0 x 2
Intel® Gigabit Ethernet x 2 (Intel® I217/I218 Gigabit PHY & Intel® I210/I211 Gigabit)
VGA Output Resolution: up to 2048 x 1536 (QXGA) @ 60 Hz
DVI-D Output Resolution: 1920 x 1200 @ 60 Hz
HDMI Output Resolution: Up to 3840 x 2160 @ 30 Hz
Mini-Card x 1 or mSATA x 1 Selected by Jumper Setting
Fanless system design
AAEON’s Hi-Safe & Hi-Manager Support

BOXER-6852

Fanless Embedded Box PC with Intel® QM87 Chipset and PCIe Expansion

Features

Reliable System with Cable-less Design
Intel® Core™ i5-4402E (2.7 GHz)
Mini-Card Slot x 2 (USB & PCIe Signal) & PCIe [x1] x 2
Rich I/O with Proctection
Isolated RS-232/422/485 x 2

BOXER-6652

Fanless Embedded controller with Intel® QM87 chipset

Features

Cable-less Design
Intel® Core™ i5-4402E (2.7 GHz)
Mini-Card Slot x 2 (USB & PCIe Signal)
Isolated RS-232/422/485 x 2

BOXER-6651

Fanless Embedded Controller With Intel® SOC ATOM Quad Core 1.91Ghz Processor E3845


Features

Intel® Atom™ E3845 Quad Core 1.91 GHz Processor SoC
COM x 6: Isolated RS-232/422/485 x 2 + RS-232 x 4
USB 3.0 x 1, USB 2.0 x 5
Two Intel® Gigabit Ethernet LAN
IntelR HD Graphics Engine
VGA + DVI-D output
SATA 3.0 Gb/s
DDR3L 1333 SODIMM x 1, Memory up to 8 GB

BOXER-6638U

Fanless Embedded Box PC with 5th Generation Intel® Core™ i3 Processor SoC

Features

U-Series CPU: Intel® Core i3-5010U
Good for Industrial Use with 4 COM Ports
Wide Temperature Support: -20°C ~ 60°C
Wide Voltage Support: 9 – 24 V

BOXER-6639

Fanless Embedded Box PC with Intel® Gen 6th Skylake Socket Type Processor and Q170 Chipset

Features

Extreme Computing Power & Graphic Display Capabitility
Desktop Grade Socket Type Processor with Longevity Support
Support DDR4 ECC or Non-ECC SO-DIMM, Up to 32GB
Support VGA + HDMI x 2 Triple Display, HDMI 4K Display
Support USB 3.0 x 4, USB 2.0 x 2
Support Intel industrial-grade GbE LAN x3
Support BIOS Selectable RS-232/422/485 x6
Compact Size and Easy Access Design
Wide Range DC 9~36V Input
32-bit Digital Input and Output

BOXER-6615

Fanless Embedded Box PC with Intel® Pentium® N3710, 1.6 GHz

Features

Intel® Pentium® N3710 1.6GHz
6COMs: 2 x RS232/422/485 + 4 x RS-232
USB3.0 x 2, USB2.0 x 2
VGA + HDMI output, support dual view / simultaneous display
Support 2.5” drive bay x 1, mSATA
Support 8 channel DIO x 1
DDR3L 1600 SODIMM x 1, Memory Max. up to 8GB
AAEON’s Hi-Safe Support

BOXER-6616

Fanless Embedded controller with Intel® Pentium N4200 or Celeron® N3350 Processor

Features

Pentium® N4200 2.5GHz/Celeron® N3350 2.4GHz
DDR3L 1866 SODIMM x 1, Memory Max. up to 8GB
COM x 6: RS-232/422/485 x 2 + RS-232 x 4
USB3.0 x 4
VGA + HDMI Output, Support Dual View/Simultaneous Display
Support 2.5” Drive Bay x 1, mSATA
Support 8 Channel TTL Level DIO x 1 (Optional)
AAEON’s Hi-Safe Support
Support DC 9~24V with Power Protection
Wide Operating Temperature: -20°C ~ 60°C
AT/ATX Switch, Remote Power On/Off Switch, Reset Button

BOXER-6839

Fanless Embedded Box PC with 6th/ 7th Generation Intel® Core™ Desktop Processor and PCIe[x4] & PCI Expansion

Features

  • Extreme Computing Power & Graphic Display Capability
  • Desktop Grade Socket Type Processor with Longevity Support
  • DDR4 ECC or Non-ECC SODIMM, Up to 32GB
  • VGA + HDMI x 2 Triple Display, HDMI 4K Display
  • PCIe [x4] & PCI Expansion
  • USB 3.0 x 6
  • Intel® Industrial-grade GbE LAN x 3
  • Support BIOS Selectable RS-232/422/485 x 6
  • Easy Access Design
  • Wide Range DC 9~36V Input
  • 34-bit Digital Input and Output

AIOT-QG

Embedded IoT Gateway with Intel® Quark SoC X1000 Series

Features

  • Intel® Quark SoC X1000 Series
  • Onboard 1GB DDR3 800MHz SODIMM
  • USB 2.0 x 2
  • Serial Port x 2 (RS-232/422/485 x 1, RS-232 x 1)
  • 10/100 Ethernet x 2
  • VDC 9~24V (Lockable VDC connector)
  • 8 bit DIO( Input/ Output)
  • 7 bit Analog Input
  • Moon Island Capable with McAfee Security

AIOT-QM

Outdoor IoT Gateway with Intel® Quark SoC Series with IP67 Rating

Features

  • Intel® Quark SoC Series
  • Onboard 1 GB DDR3 800MHz SODIMM
  • USB 2.0 x 2
  • Serial Port x 1 (RS-232/422/485 x 1)
  • 10/100 Ethernet x 1
  • VDC 9~24V (Lockable VDC Connector)
  • DIO (Input/ Output) x 8 pins
  • Moon Island Capable with McAfee Security

AIOT-QA

Din-Rail Mounted Embedded IoT Gateway with Intel® Quark SoC X1000 Series for Automation

Features

  • Intel® Quark SoC X1000 Series
  • Onboard 1GB DDR3 800MHz SODIMM
  • USB 2.0 x 2
  • Serial Port x 2 (RS-232/422/485 x 1, RS-232 x 1)
  • 10/100 Ethernet x 2
  • VDC 9~24V (Lockable VDC connector)
  • 8 bit DIO( Input/ Output)
  • 7 bit Analog Input
  • Moon Island Capable with McAfee Security

AIOT-DRM

Din-Rail Modular Gateway for Building Management System

Features

  • Intel® Quark SoC Series
  • Onboard 512MB DDR3 800MHz SODIMM
  • Industrial I/Os: DI x6, DO x 2, ADC x4, DAC x 1, Isolated RS-485 x 1
  • LAN x 1, USB x 1, RS232 x 1
  • mPCIe card slot x 1 for Wireless Connectivity
  • Fan-less Cooling System
  • Modular Design-Easy to Customize
  • Moon Island Capable with McAfee Security
  • Onboard 4 GB eMMC Storage

UP-GWS01

Tiny Gateway System with UP Board

Features

  • Intel® Cherry Trail x5-Z8350 SoC
  • Onboard DDR3L Memory
  • Onboard eMMC Storage
  • Gigabit LAN x 1, USB 2.0 x 4, USB 3.0 x 1, HDMI x 1
  • Optimized Fanless Cooling Design
  • Wi-Fi (Optional)
  • BT 4.0 (Optional)

UP-LRS01

Intel® LORA Gateway System

Features

  • Intel® Atom™ x5-Z8350 SOC
  • Onboard 4 GB DDR3L Memory, 64 GB eMMC Storage
  • Gigabit LAN x 1, HDMI x 1
  • USB 2.0 x 4, USB 3.0 OTG x 1
  • LORA Function Supported
  • Raspberry Pi HAT 40-Pin Compatible

AIOT-X1000

3.5” SubCompact Board with Intel® Quark SoC X1000 Series

Features

  • Intel® Quark SoC X1000 Series
  • Onboard 1GB DDR3 800 SODIMM
  • Micro SD Slot x 1
  • USB 2.0 x 4
  • Serial Port x 2 (RS-232/422/485 x 2)
  • Moon Island Capable with McAfee Security
  • VDC 5V or 9~24V (Phoenix/Lockable VDC connector)
  • B10-01: Wind River- X1021 SoC with Secure Boot, license fee payable to Wind River
  • B10-03: Yocto – X1000 SoC without Secure Boot, OS free of charge

UP Board

Computer Board for Professional Makers

Features

  • Compatible with most of Raspberry Pi HAT
  • Quad Core Intel CPU and Graphic performance
  • Developer Community Support (www.up-community.org)
  • Rich Linux support (Debian-Ubilinux, Ubuntu, yoctoLinux)
  • Windows 10 Support
  • Ubiworx IoT framework with Cloud service
  • Scalable IO module integration
  • Industrial level product and backend Support

ACD-110D

10.1” WXGA Multi Touch Display

Features

  • 10.1″ WXGA (1280 x 800) TFT LCD Display
  • IP65 Aluminum Front Bezel
  • P-CAP Multi-Touch Screen (2-point)
  • VESA 75/ Panel Mount/ Stand

ACD-515D

15.6″ WXGA Infotainment Touch Display

Features

  • 15.6″ WXGA (1366 x 768) TFT LED type LCD
  • Multi-Touch Window Design (2-Point)
  • IP65 Front Bezel & IPX1 Back Chassis
  • 7H Anti-Scratch Surface
  • Smart Card Reader, Magnetic Stript Reader, Camera
  • Fanless Operation
  • Easy To Clean

AGD-312D V2

12.1” XGA Rugged Touch Display

Features

  • 12.1” XGA (1024 x 768) TFT LCD Display
  • I P65 Aluminum Die Cast Front Bezel
  • 5-Wire Resistive Touch/ Non-Touch Screen Supported
  • Power Protection: (DC 12V/ DC 9-30V)/ Over-Voltage Protection/ Under-Voltage Protection/ Reverse-Voltage Protection
  • Flexible Interfaces: DVI/VGA For Video Input/ RS-232 For Touch Screen

AGD-315D V2

Features

  • 15″ XGA (1024 x 768) TFT LCD Display
  • IP65 Aluminum Die Cast Front Bezel
  • 5-wire Resistive Touch Screen
  • Power Protection:(DC 9-30V)
  • Over-Voltage Protection/ Under-Voltage Protection/ Reverse-Voltage Protection

  • Flexible Interfaces:
  • DVI/VGA For Video Input/ RS-232 For Touch Screen

AGD-315D

15″ XGA Rugged Touch Display

Features

  • 15″ XGA (1024 x 768) TFT LCD Display
  • IP65 Aluminum Die Cast Front Bezel
  • 5 -wire Resistive Touch Screen
  • Two Front USB Ports
  • Power Protection: (DC 9-30V)
  • -Over-Voltage Protection
  • -Under Voltage Protection
  • -Reverse-Voltage Protection
  • Flexible Interfaces:
  • -DVI/VGA For Video Input
  • -RS-232/ Mini-USB For Touch Screen
  • Easy To Maintain

AGD-317D

17″ SXGA Rugged Touch Display

Features

  • 17” SXGA (1280 x 1024) TFT LCD Display
  • IP65 Aluminum Die Cast Front Bezel
  • 5-wire Resistive Touch Screen
  • Two Front USB Ports
  • Power Protection: (DC 9-30V)
  • -Over-Voltage Protection
  • -Under Voltage Protection
  • -Reverse-Voltage Protection
  • F lexible Interfaces:
  • -DVI/VGA For Video Input
  • -RS-232/ Mini-USB For Touch Screen
  • Easy to Maintain

AEV-6356

Railway Box PC With Onboard Intel Core i7/ Celeron M Processo

Features

  • Onboard Intel® Core™ i7-3517UE or Celeron® 827E
  • EN50155 Certification
  • Isolation RS-232/422/485 x 1
  • Isolation Digital Input x 6 + Digital Output x 2
  • Wireless Solution: WiFi/ 3G/ GPS
  • Rugged M12 Connector for LAN/ Serial/ USB/ Power
  • Power Input: 17V~30V Certificated, and 17V~75V Compliant
  • Supports OVP/UVP/SCP/Reverse Protection

BOXER-6357VS

Railway Embedded Computer with Intel® Core™ i7-3517UE Processor

Features

  • Onboard Intel®™ Core i7-3517UE
  • Isolated RS-232/422/485 x 1/ Power (OVP/ LVP/ SCP)
  • Isolated Digital Input x 4 + Digital Output x 2
  • Wi-Fi/ 4G/ GPS
  • 12 ~ 36V, 16.5 ~ 75V, 43 ~ 160V Power Input
  • Rugged M12 Connector for LAN/ Serial/ USB/ Power
  • EN50155Tx Certified
  • EN45545 Certified

ACP-1104

10.1” WXGA Ultra-slim Fanless Multi Touch Panel PC w/ Intel® Atom™ J1900/ N2807 Processor, 2GB RAM

Features

  • 10.1″ WXGA (1280 x 800) Color TFT LCD Display
  • Intel® Celeron® J1900/ N2807 Processor
  • Aluminum Design
  • P-CAP Multi-touch (2-point)
  • Fanless Operation
  • VESA 75/ Panel Mount/ Stand Support
  • IP65 Compliant Front Beze

ACP-1103

10.1” Ultra-Slim Fanless Multi-Touch Panel PC with Intel® Atom™ N2600, 2 GB RAM

Features

  • 10.1″ WXGA (1280 x 800) Color TFT LCD Display
  • Intel® Atom™ N2600 Processor
  • Wide Flat-screen with P-CAP Multi-touch (2-point)
  • 7H Anti-Scratch Surface
  • Thickness: 13mm LCD + Touch, and 20mm Chassis
  • Aluminum Design
  • IP65 Compliant
  • Fanless Operation
  • VESA 75/Panel Mount/ Stand Support

ACP-5182

18.5″ Fanless Multi-Touch Window Computer with Onboard Intel® Dual Core Atom™ D510 Processor

Features

  • 18.5″ WXGA (1366 x 768) Fanless TFT LCD Display
  • Onboard Intel® Dual Core Atom™ D510 Processor
  • Easy-To-Clean: Multi-Touch Window Design (Two-Point)
  • IP65 Front Bezel & IPX1 Back Chassis
  • Anti-Scratch Surface (7H Hardness)
  • Smart Card Reader/ MSR/ Camera Support (Optional)

ACP-5217

21.5” Fanless Multi-Touch Computer With Intel® Core™ i7/i5/Celeron® 1020E Processor, 2 GB RAM

Features

  • 21.5″ Full HD (1920 x 1080) TFT LCD Display
  • Multi-Touch Window Design (2-Point Under Windows® Professional Version)
  • Intel® Core™ i7/i5 Celeron® Processor
  • IP65 Front Bezel & IPX1 Back Chassis
  • Anti-Scratch Surface (7H Hardness)
  • Smart Card Reader/ Magnetic Stripe Reader/ Camera Support (Optional)
  • Easy to Clean
  • Fanless Operation

ACP-5153

15.6” Fanless Multi-Touch Panel PC with Intel® Atom™ D2550 Processor, 2 GB RAM

Features

  • 15.6″ (1366 x 768) Color TFT LCD Display
  • Intel® Atom™ D2550 Processor
  • Widescreen with P-CAP Multi-Touch (2-point)
  • 7H Anti-Scratch Surface
  • IP65 Compliant Front Bezel
  • Fanless Operation

ACP-2153

15” Multi-Touch Panel Computer With Intel® Atom™ D2550 1.86 GHz Processor, 2 GB RAM

Features

  • 15″ XGA (1024 x 768) Color TFT LCD Display
  • Open-Frame Design (Without Edge)
  • P-CAP Multi-touch (2-point)
  • Intel® Atom™ D2550 Processor
  • Fanless Operation
  • VESA 75/100 and Panel Mount Support

ACP-1073

7” Ultra-Slim Fanless Multi-Touch Panel PC with Intel® Atom™ N2600, 2 GB RAM

Features

  • 7″ WSVGA (1024 x 600) Color TFT LCD Display
  • Intel® Atom™ N2600 Processor
  • Wide Flatscreen with Projected Capacitive Multi-Touch (2-point)
  • 7H Anti-Scratch Surface
  • Thickness: 13mm LCD + Touch, and 20mm Chassis
  • Aluminum Design
  • IP65 Compliant
  • Fanless Operation
  • VESA 75 stand Support

ACP-1074

7” Ultra-Slim Fanless Multi-Touch Panel PC with Intel J1900/N2807, 2GB RAM

Features

  • 7″ WSVGA (1024 x 600) Color TFT LCD Display
  • Intel N2807/J1900 Processor
  • Wide Flatscreen with P-CAP Multi-Touch (10-point)
  • 7H Anti-scratch Surface
  • Aluminum Design
  • IP65 Compliant
  • Fanless Operation
  • VESA 75/Panel Mount/ Stand Support

AFP-6123

12.1” Stainless Fanless Touch Panel Computer With Intel® Atom™ D2550 Processor, 2 GB RAM

Features

  • 12.1” XGA (1024 x 768) TFT LCD Display
  • Intel® Atom™ D2550 Processor, Fanless Operation
  • IP66/NEMA4x-Compliant Stainless Type 316L System
  • Supports Wide Operation Temperature : -20°C ~ 50°C
  • Power Input Protection:
  • -Over-Voltage Protection
  • -Low-Voltage Protection
  • -Reverse-Voltage Protection
  • Note: Factory-installed Storage Device is recommended for IP66 Protection.

AFP-6152

15” Stainless Fanless Touch Panel Computer With Intel® Atom™ D525 Processor, 2 GB RAM

Features

  • 15” XGA (1024 x 768) TFT LCD Display
  • Intel® Atom™ D525 Processor, Fanless Operation
  • IP66/NEMA4x-Compliant Stainless Type 316L System
  • Supports Wide Operation Temperature : -20°C ~ 50°C
  • Power Input Protection:
  • -Over-Voltage Protection
  • -Low-Voltage Protection
  • -Reverse-Voltage Protection
  • Note: Factory-installed Storage Device is recommended for IP66 Protection.

OMNI-2215-BT

21.5″ Modular HMI Panel PC with Intel Celeron J1900/ N2807 Processor

Features

    • 21.5″ WXGA (1920 x 1080) Color TFT LCD Display
    • Intel® N2807/J1900 Processor
    • P-CAP or Resistive Touch Support
    • Multiple touchscreen
    • Aluminum Design
    • IP65 Compliant Front Bezel
    • Fanless Operation
    • Power Input Protection: Over-Voltage Protection, Low-Voltage Protection, Reverse-Voltage Protection
    • Easily Expandable I/O by AAEON OMNI I/O Modules

Note:*RAM not included *Panel Mount Kit (Optional)

OMNI-3155-BT

15” Modular HMI Panel PC with Intel® Celeron® J1900/ N2807 Processor

Features

    • 15” WXGA (1024 x 768) TFT LCD Display
    • Intel® N2807/J1900 Processor
    • P-CAP or Resistive Touch Support
    • Aluminum Design
    • IP65 Compliant Front Bezel
    • Fanless Operation
    • Easily Expandable I/O by AAEON OMNI I/O Module

Note:*RAM not included *Panel Mount Kit (Optional)

OMNI-3125-BT

Features

    • 12.1” WXGA (1024 x 768) TFT LCD Display
    • Intel® N2807/J1900 Processor
    • P-CAP or Resistive Touch Support
    • Aluminum Design
    • IP65 Compliant Front Bezel
    • Fanless Operation

Note:*RAM not included *Panel Mount Kit (Optional)

OMNI-3105-BT

Features

    • 10.4” WXGA (800 x 600) TFT LCD Display
    • Intel® N2807/J1900 Processor
    • P-CAP or Resistive Touch Support
    • Aluminum Design
    • IP65 Compliant Front Bezel
    • Fanless Operation

Note:*RAM not included *Panel Mount Kit (Optional)

OMNI-2215-SKU

21.5” Modular HMI Panel PC with Intel® 6th Generation i5-6300U/C-3955U Processor

Features

  • 21.5” FHD (1920 x 1080) TFT LCD Display
  • Intel® 6th Generation i5-6300U/C-3955U Processor
  • P-CAP or Resistive Touch Support
  • Aluminum Design
  • IP65 Compliant Front Bezel
  • Fanless Operation
  • Easily Expandable I/O by AAEON OMNI I/O Modules

OMNI-2155-SKU

15.6” Modular HMI Panel PC with Intel® 6th Generation i5-6300U/ Celeron® 3955U Processor

Features

  • 15.6” FWXGA (1366 x 768) TFT LCD Display
  • Intel® 6th Generation i5-6300U/C-3955U Processor
  • P-CAP or Resistive Touch Support
  • Aluminum Design
  • IP65 Compliant Front Bezel
  • Fanless Operation
  • Power Input Protection: Over-Voltage Protection, Low-Voltage Protection, Reverse-Voltage Protection
  • Easily Expandable I/O by AAEON OMNI I/O Modules

OMNI-3105-SKU

10.4” Modular HMI Panel PC with Intel® 6th Generation i5-6300U/C-3955U Processor

Features

  • 10.4” WXGA (800 x 600) TFT LCD Display
  • Intel® 6th Generation i5-6300U/C-3955U Processor
  • P-CAP or Resistive Touch Support
  • Aluminum Design
  • IP65 Compliant Front Bezel
  • Fanless Operation

OMNI-3125-SKU

12.1” Modular HMI Panel PC with Intel® 6th Generation i5-6300U/C-3955U Processor

Features

  • 12.1” WXGA (1024 x 768) TFT LCD Display
  • Intel® 6th Generation i5-6300U/C-3955U Processor
  • P-CAP or Resistive Touch Support
  • Aluminum Design
  • IP65 Compliant Front Bezel
  • Fanless Operation

OMNI-3155-SKU

Features

  • 15” WXGA (1024 x 768) TFT LCD Display
  • Intel® 6th Generation i5-6300U/C-3955U Processor
  • P-CAP or Resistive Touch Support
  • Aluminum Design
  • IP65 Compliant Front Bezel
  • Fanless Operation
  • Easily Expandable I/O by AAEON OMNI I/O Modules

OMNI-3175-SKU

17” Modular HMI Panel PC with Intel® 6th Generation i5-6300U/C-3955U Processor

Features

  • 17” WXGA (1280 x 1024) TFT LCD Display
  • Intel® 6th Generation i5-6300U/C-3955U Processor
  • P-CAP or Resistive Touch Support
  • Aluminum Design
  • IP65 Compliant Front Bezel
  • Fanless Operation
  • Easily Expandable I/O by AAEON OMNI I/O Modules

OMNI-3195-SKU

Features

  • 19” WXGA (1280 x 1024) TFT LCD Display
  • Intel® 6th Generation i5-6300U/C-3955U Processor
  • P-CAP or Resistive Touch Support
  • Aluminum Design
  • IP65 Compliant Front Bezel
  • Fanless Operation
  • Easily Expandable I/O by AAEON OMNI I/O Modules

OMNI Series Modules- I/O

OMNI Series Modules- I/O Modules

OMNI Series Modules- Panels

OMNI Series Modules- Panels

OMNI Series Modules- CPU BOX kit

Features

    Intel® 6th Gen. Processor

  • Intel® i5-6300U/C-3955U Processor
  • Aluminum Design
  • Fanless Operation
  • Easily Expandable I/O by AAEON OMNI I/O Modules
    Intel® Atom™ Processor

  • Intel® N2807/J1900 Processor
  • Aluminum Design
  • Fanless Operation
  • Easily Expandable I/O by AAEON OMNI I/O Modules

AHP-2122

Features

  • 12.1″ XGA (1024 x 768) TFT LCD Display
  • Intel® Atom™ D525 Processor
  • Fanless Operation
  • Wide Operation Temperature: -20˚C ~ 60˚C
  • IP65 Aluminum Die Cast Front Bezel
  • 12.1″ LCD with 1000/500 Nits XGA LED Backlight
  • Two Easy Access Front USB Ports
  • Power Input Protection:
  • -Over-Voltage protection
  • -Low-Voltage protection
  • -Reverse-Voltage Protection

AHP-2153

15″ Rugged Fanless Touch Panel Computer with Onboard Intel® Atom™ D2550 Processor

Features

  • 15″ XGA (1024 x 768) TFT LCD Display
  • Intel® Atom™ D2550 Processor
  • Fanless Operation
  • Wide Operation Temperature: -20˚C ~ 60˚C
  • IP65 Aluminum Die Cast Front Bezel
  • 15” LCD with 400 Nits XGA LED Backlight
  • Two Easy Access Front USB Ports
  • Power Input Protection:Over-Voltage Protection/ Low-Voltage Protection/ Reverse-Voltage Protection

AHP-2173

17” Rugged Fanless Touch Panel Computer with Intel® Atom™ D2550 Onboard, 2G RAM Inside

Features

  • 17” SXGA (1280 x 1024) TFT LCD Display
  • Intel® Atom™ D2550 Processor, 1.86 GHz
  • Fanless Operation
  • Aluminum Die Cast Front Bezel
  • IP65 Front Bezel
  • Power Input Protection:
  • -Over-Voltage Protection
  • -Low-Voltage Protection
  • -Reverse-Voltage Protection

AHP-2176

17” Rugged Fanless Touch Panel Computer With Intel® Celeron® 827E/ Core™ i7-2610UE Processor, 2GB RAM

Features

  • 17″ SXGA (1280 x 1024) TFT LCD Display
  • Intel® Celeron® 827E/ Core™ i7-2610UE Processor
  • Fanless Operation
  • IP65 Aluminum Die Cast Front Bezel
  • Two Easy Access Front USB Ports
  • Power Input Protection:
  • -Over-Voltage Protection
  • -Low-Voltage Protection
  • -Reverse-Voltage Protection
  • -Surge Protection

AHP-1070

7″ WVGA LED PC with TI OMAP 600 MHz Processor

Features

  • Onboard TI OMAP 600 MHz
  • 7″ 300 Nits WVGA LED Backlight
  • Fanless Operation
  • 256MB Flash ROM, Max 256MB DDR
  • Slim Design: 45 mm

AHP-1083

8.4 ” SVGA HMI Touch Panel Computer With Onboard Intel® Atom™ D2550 1.86 GHz Processor, 2 GB RAM

Features

  • Onboard Intel® Atom™ D2550 1.86 GHz
  • 8.4″ LCD with 450 Nits SVGA LED Backlight
  • Fanless Operation
  • IP65 Front Bezel

AHP-1154

15” Fanless Touch Panel with Intel Celeron J1900/N2807

Features

  • Intel® Celeron® J1900, 2.0 GHz/ N2807, 1.58 GHz
  • 15″ LCD with 450 nits XGA LED Backlight
  • IP65 Plastic Front Bezel
  • RS-232/422/485 x 2, RS-232 x 2
  • Fanless Operation
  • Support DC 12V/ DC 9~30V

AHP-1123

12.1” XGA HMI Touch Panel PC With Onboard Intel® Atom™ D2550 1.86 GHz Processor, 2 GB RAM

Features

  • 12.1″ LCD with 500 Nits XGA LED Backlight
  • Onboard Intel® Atom™ D2550 1.86 GHz
  • IP65 Plastic Front Bezel
  • Supports Dual Gigabit Ethernet
  • Fanless Operation

AHP-1125

12.1” XGA Touch Panel PC with Onboard Intel® N3710/N3060 Processors, 2 GB RAM

Features

  • 12.1″ LCD with 500 Nits XGA LED Backlight
  • Onboard Intel® N3710/N3060 Processor
  • IP65 Plastic Front Bezel
  • DC 12V/ DC 9-30V
  • Fanless Operation

FWS-7350

1U Rackmount 4 LAN Ports Network Appliance with Intel® Atom™ Processor SoC

Features

  • 1U Rackmount 4 LAN Ports Network Appliance
  • Onboard Intel® Atom™ C2558/C2758 Quad-Core/ Octo-Core 2.4GHz SoC Processor
  • 240-Pin Dual-Channel ECC or Non-ECC DDR3(L) 1600MHz DIMM x 4, Up to 64 GB
  • Gigabit Ethernet x 4
  • Optional Up to 2 Pairs LAN Bypass Function
  • 3.5” SATA HDD x 1 or 2.5” SATA HDD x 2 and CF Socket x 1
  • RJ-45 Console x 1, USB2.0 x 2
  • Optional NIM Slot x 1
  • Optional PCI-E ﹝x4﹞ x 1
  • ATX PSU 100W
  • Mini-PCIe Slot x 1

FWS-7811

Features

  • 1U Rackmount Network Appliance
  • LGA1150 4th Generation, Intel® Core™/Xeon Processor
  • 240-pin ECC/non-ECC DDR3(L) 1333/1600 UDIMM x 4 Up to 32 GB
  • Intel® i211AT 10/100/1000Base-TX Ethernet x 8 (Optional up to 2 Pair LAN Bypass Function)
  • Up to 16 Ports and 6 Pairs Bypass with NIM Series
  • Up to 2.5” SATA HDD x 5 or 2.5” SATA HDD x 3 + 3.5” SATA HDD x 1
  • LCM with Keypad x 1
  • RJ-45 for Console x 1, USB3.0 x 2
  • 275W Redundant AC Type Power Input Requirement
  • VGA Header x 1 (Optional VGA Cable)

FWS-7400

Features

  • 1U Rackmount Network Appliance
  • Intel® LGA1150 4th Gen Core™ Processor
  • 240-pin DDR3L 1333/160 MHz DIMM x 2, Up to 16GB
  • Gigabit Ethernet x 6 (Optional LAN Bypass Function up to 2 Pairs)
  • Internal 3.5” SATA HDD x 1 or 2.5” SATA HDD x 2
  • LCM with Keypad x 1
  • RJ-45 for Console x 1, USB3.0 x 2
  • 250W AC Power Input
  • VGA Header x 1 (Optional VGA Cable with Rear Bracket)

FWS-7810

1U Rackmount 8 LAN Ports Network Appliance with Intel® C226 Chipset

Features

  • 1U Rackmount Network Appliance
  • Intel® LGA1150 4th Gen Core™ / Xeon Processor
  • 240-pin ECC DDR3 1333/1600MHz DIMM x 4, Up to 32GB
  • 10/100/1000Base-TX Ethernet Port x 8
  • Internal 3.5″ SATA HDD x 1 or 2.5″ SATA HDD x 2, CF slot x 1
  • LCM with keypad x 1
  • RJ-45 for Console x 1, USB3.0 x 2
  • 250W AC power input
  • RAID 0,1 Supported
  • VGA Header x 1
  • Support Bypass Function Type II (Up To 2 Pairs)

FWS-7520

4 Gigabit Ethernet Ports 1U Rackmount Network Appliance with Intel® Atom™ E3845/ Celeron® J1900 Processor SoC

Features

  • 4 LAN ports Network Appliance
  • Intel® Atom™ E3845, up to 1.91GHz/ Celeron® J1900 up to 2.42GHz
  • 204-pin Dual-channel DDR3/L 1333 MHz SODIMM x 2, up to 8 GB
  • Intel® I210AT, 10/100/1000Base-TX Ethernet x 4
  • 2.5” HDD x 1 (Optional), CompactFlash™ Socket x 1
  • RJ-45 Console x 1, USB2.0 x 2
  • 100W ATX PSU

FWS-7250

4 Gigabit Ethernet Ports 1U Rackmount Network Appliance with Intel® Atom™ E3845/ Celeron® J1900 Processor SoC

Features

  • 4 LAN ports Network Appliance
  • Intel® Atom™ E3845, up to 1.91GHz/ Celeron® J1900 up to 2.42GHz
  • 204-pin Dual-channel DDR3/L 1333 MHz SODIMM x 2, up to 8 GB
  • Intel® I210AT, 10/100/1000Base-TX Ethernet x 4
  • 2.5” HDD x 1 (Optional), CompactFlash™ Socket x 1
  • RJ-45 Console x 1, USB2.0 x 2
  • 100W ATX PSU

FWS-7520

1U Rackmount Network Appliance, Intel® Xeon™ Processor SoC with 3 NIM

Features

  • 1U Rackmount Network Appliance
  • Intel® FCBGA Xeon D-1548/D-1518 (Optional) SOC
  • 288-pin ECC DDR4 x 4 1600/1867/2133MHz RDIMM Up to 128GB
  • 10/100/1000Base-TX up to 24 Ethernet ports (Optional by NIM modules)
  • 10GbE SFP+ x 2
  • IPMI (AST2500) Port x 1, VGA/BMC/KVMoIP Supported (Optional)
  • Support 2.5” SATA HDD x 2
  • LCM with Keypad x 1
  • RJ-45 for Console x 1, USB 3.0 x 2
  • 250W AC type/ 220W Redundant Power Input Requirement

FWS-8500

2U Rackmount High Performance Network Appliance, up to 64 Gigabit Ethernet Ports

Features

  • 2U Rackmount Network Appliance
  • Dual Intel® Xeon® Processor E5-2600 v3 Series Processor, LGA 2011
  • Intel® Communications Chipset 8925
  • 288-pin DDR4 1600/1866/2133 MHz DIMM (8 DIMM Per CPU) RDIMM x 16, Up to 512 GB
  • Up to 64 Gigabit Ethernet Ports Via NIM
  • Internal 3.5” SATA HDD x 1 or 2.5” SATA HDD x 2, CompactFlash™ Socket x 1
  • Optional Parallel LCM with Keypad x 1
  • RJ-45 Console x 1, USB 2.0 x 2, 1 GbE LAN x 1
  • 650W Redundant Power
  • Mini-PCIe x 1, PCI-E [x8] x 2 (Optional)

FWS-7820

1U Rackmount Network Appliance, Intel® C236, with up to 5 Network Interface Bays

Features

  • 1U Rackmount Network Appliance
  • 6th/7th Gen. Intel® LGA1151 Core™/ Xeon Processor
  • 288-pin DDR4 1600/1866/2133 MHz ECC/U-DIMM x 4 Up to 64 GB
  • Up to 10/100/1000Base-TX Ethernet Port x 40 (Depends on NIM)
  • Up to 2 SATA 6 GB Ports (Internal 3.5” SATA HDD x 1 or 2.5” SATA HDD x 2) *mSATA/ CF/ CFast will be Disabled if 2nd SATA HDD is Used
  • CF Socket x 1 (Can be Replcaed by CFast™ Socket or mSATA Slot)
  • LCM with Keypad x 1 (3 NIM Slots SKU)
  • RJ-45 for Console x 1, USB 3.0 x 2
  • 250W AC Type Power Input Requirement
  • VGA Header x 1 (Optional VGA Cable)

FWS-7821

Features

  • 1U Rackmount Network Appliance
  • Intel® LGA1151 6th/7th Generation Core™/Xeon Processors
  • 288-pin ECC Dual Channel DDR4 2133 UDIMM x 4 Up to 64GB
  • 10/100/1000Base-TX Ethernet Ports x 8 (Onboard RJ-45 x 6 & SFP x 2) with Max. 3 Pairs of LAN Bypass Function
  • Internal 3.5” SATA HDD x 1 or 2.5” SATA HDD x 2 (Optional Extra 4 pcs x 2.5” HDD without NIM and Expansion Lot Presented)
  • CFast x 1 (Optional CF Socket or mSATA Slot)
  • 8 bits GPIO (Default 4-bits Input, 4-bits Output)
  • TPM Supported (Optional Request), RAID 0,1 Supported
  • LCM with keypad x 1, RJ-45 for Console x 1, USB3.0 x 2
  • 250W AC Type Power Input
  • VGA Header x 1 (Optional VGA Cable)

FWS-2252

Desktop 4 LAN Ports Network Appliance with Intel® Celeron® J1900 Processor

Features

  • Intel® Celeron® J1900 Processor
  • 204-pin Dual-channel DDR3L 1333MHz SODIMM x 2, Up to 8 GB
  • 10/100/1000Base-TX Ethernet Port x 4
  • 2.5” HDD Bay x 1
  • CompactFlash™ socket x 1
  • Mini-Card Slot x 1
  • RJ-45 Console x 1, USB 3.0 x 1, USB 2.0 x 2

FWS-2160

Desktop AMD G-series T24L + A50M 6 LANs Network appliance

Features

  • 6 LAN Ports Network Appliance
  • Onboard AMD G-series T24L 1.0 GHz Processor
  • AMD A50M Chipset
  • 240-pin Single Channel DDR3 1066MHz DIMM x 2, Up to 8GB
  • 10/100/1000Base-TX x 6 (Optional LAN bypass function up to 2 pairs)
  • 2.5” SATA HDD x 1 and CompactFlash™ Socket x 1
  • RS-232 Console x 1, USB2.0 x 2
  • DC 12V Power Input Requirement
  • Mini-PCIe Slot x 2

FWS-2350

Features

  • Onboard Intel Atom C2358/C2558 Processor SoC
  • 240-pin ECC DDR3 DIMM or non-ECC SDRAM, Up to 16GB
  • Built-in Gigabit Ethernet x 6
  • Supports QuickAssist Crypto Acceleration
  • Built-in Intel® i211AT LAN Controller and Marvell PHY 88E1543
  • System Cooling Fan x 1
  • Supports 2 Pairs with LAN Bypass Function
  • Compact Desktop Design
  • Built-in Intel® i211AT LAN and Intel® SoC Integrated i354 with Marvell 88E1543 PHY

FWS-2250

Desktop 4 LAN Ports Network Appliance with Intel® Atom™ E3815/E3827/Celeron® J1900 Processor SoC

Features

  • 4 LAN Ports Network Appliance
  • Onboard Intel Atom E3815 / E3827 / J1900 SoC Processor
  • 204-pin DDR3L 1066/1333 MHz SODIMM x 2, up to 8GB
  • 10/100/1000 Base-TX Ethernet x 4 (up to 1 pair Bypass)
  • CF Socket x 1
  • RJ-45 Console x 1, USB2.0 x 2, USB3.0 x 1
  • 12V DC Power Input
  • Mini-Card Socket x 1 (Optional)

FWS-2251

Desktop 4 LAN Ports Network Appliance with Intel® Celeron® Processor J1900

Features

  • 4 LAN Ports Network Appliance
  • Onboard Intel® Celeron® Processor J1900 2GHz
  • 2 x 204-pin Dual Channel DDR3L 1333MHz SODIMM, Up to 8GB
  • 10/100/1000Base-TX Ethernet port x 4
  • Onboard SATA II port x 1
  • RJ-45 console x 1, USB3.0 x 1
  • DC 12V Power Input Requirement
  • Mini-Card Socket x 3 (Half Size x 1, Full Size with SIM Socket x 1, USB 2.0 Signal only Full size with dual SIM socket x 1)
  • Accessible SIM socket
  • Support Antenna x 6
  • Fanless

FWS-2260

Desktop 6 LAN Ports Network Appliance with Intel® Celeron® N3160/N3060 Processor SoC

Features

  • Onboard Intel® Pentium® Celeron® N3000 Series Processor SoC
  • 204-pin Dual-channel DDR3L 1066/1600MHz SODIMM x 2, Up to 8 GB
  • 10/100/1000Base-TX x 6 (Optional two pairs LAN Bypass function)
  • 2.5” SATA HDD bay x 1
  • CFast™ socket x 1(optional CF socket or mSATA slot)
  • Mini-card slot (with SIM Socket) x 2 via USB Signal
  • RJ-45 console x 1, USB3.0 x 2
  • DC 12V power input requirement

FWS-2253

Desktop 4 LAN Ports Network Appliance with Intel® Celeron® N2807/J1900 Processor, Wide Temperature

Features

  • Intel® Celeron® N2807/J1900 Processor
  • 204-pin SODIMM: Intel® N2807 Single-channel DDR3L 1333 MHz x 1/ Intel® J1900 Dual-channel DDR3L 1333 MHz x 2
  • 10/100/1000Base-TX Ethernet Port x 4
  • CompactFlash™ Socket x 1
  • Mini-Card Slot x 1
  • RJ-45 Console x 1, USB 3.0 x 1, USB 2.0 x 2
  • Wide Operating Temperature Range: Intel® N2807: -20°C ~ 70°C/Intel® J1900:0°C ~ 50°C
  • Fanless

FWS-2271

Features

  • Intel® N4200/N3350 Processor SoC
  • 204-pin Dual-channel DDR3L 1867MHz SODIMM Up to 2, 16 GB
  • 10/100/1000Base-TX Ethernet Port x 6
  • CFast™ Socket x 1
  • Mini-Card Slot x 2 (USB Signal only with SIM Socket x 1)
  • Accessible SIM Cover
  • Supports TPM
  • RJ-45 Console x 1, USB3.0 x 2, HDMI x 1
  • Supports Antenna up to 4

IMBA-967

Features

  • Intel® Core™ i7/i5/i3 LGA 1155 (4C/ 2C 32nm) Processor With Graphic & Memory Controller
  • Intel® Q67
  • Dual-Channel DDR3 1066/1333 Memory, Up To 32 GB
  • Intel® 10/100/1000Base-TX Ethernet x 2 (LAN1 Supports Intel® iAMT 7.0)
  • Intel® Integrated GPU Support Dual Display By VGA, DVI, HDMI
  • HDAC With Realtek ALC662
  • SATA 6.0Gb/s and 3.0Gb/s x 6, Support RAID 0/1/5/10
  • USB2.0 x 12, COM x 6, LPT x 1 , IrDA x 1
  • PCI-E〔x16〕x 1, PCI-E〔x4〕x 1, PCI-E〔x1〕x 1 , PCI x 4

IMBA-H61A

ATX Industrial Motherboard with Intel® 2nd/3rd Generation Core™ i7/i5/i3/ Pentium® Processor

Features

  • Intel® Socket 1155 for 2nd/3rd Generation Core™ Processor
  • Intel® H61 Express Chipset
  • DDR3 1066/1333 MHz DIMM x 2, Up to 16GB
  • VGA, DVI Dual independent Display
  • Realtek RTL8111F x 2, Gigabit Ethernet x 2
  • PCI-E〔x16〕x 1, PCI-E〔x1〕x 2, PCI x 4, Mini Card x 1

IMBA-Q77

Industrial Motherboard with Intel® 3rd Generation Core™ i7/i5/i3 Processor

Features

  • Intel® 3rd Generation Core™ i7/ i5/ i3 LGA 1155 Processor
  • Intel® Q77
  • Dual-Channel DDR3 1600(Only for 3rd Gen CPU)/1066/1333 DIMM x 4, (Up to 32 GB)
  • 10/100/1000Base-TX x 2 (LAN1 Supports Intel iAMT 8.0)
  • Three Independent Displays With VGA (Onboard only), DisplayPort, DVI-D
  • SATA 3.0Gb/s x 4, SATA 6.0Gb/s x 2, Support RAID 0,1,5,10
  • USB2.0 x 8, USB3.0 x 4 , COM x 6, LPT x 1, IrDA Tx/Rx Header x 1
  • PCI-Express【x16】 x 1, PCI-Express【x4】 x 1, PCI-Express【x1】 x 2, PCI x 3
  • TPM 1.2 (Optional)

IMBA-Q87A

ATX Industrial Motherboard with Intel® 4th Generation LGA1150 Processor, SATA3 x 6, PCI x 5, Multiple Display Ports, Supports iAMT 9.0

Features

  • Intel® 4th Generation Core™ i7/ i5 /i3 22nm LGA 1150 socket Processor
  • Three/Dual Independent Display: VGA, DVI-D, HDMI, DP (HDMI optional).
  • Dual Gigabit Ethernet, LAN1 support AMT 9.0
  • SATA6.0 Gb/s x 6, USB 3.0 x 4, USB 2.0 x 10
  • Rich Expansion Slot: PCI-E 3.0/2.0〔x16〕x 1, PCI-E〔x4〕x 1, PCI x 5
  • TPM supported

IMBM-H61A

Micro-ATX Industrial Motherboard with Intel® 2nd/3rd Generation Core™ i7/i5/i3 Processor

Features

  • Intel® 2nd/3rd Generation Core™ i7/ i5/ i3 Processor
  • Intel® H61
  • VGA x 1, DVI x 1, LVDS x 1
  • Gigabit Ethernet x 2
  • COM x 13 (RS-232 x 11, RS-232/422/485 x 2)
  • SATA 3.0Gb/s x 3 + CFast Socket x 1 Support
  • Multiple Expansion Slot: PCI-E 2.0 [x16] x 1, PCI-E 2.0 [x1] x 1, PCI x 1, Mini Card x 1

IMBM-B75A

Micro-ATX Industrial Motherboard with Intel® 2nd/3rd Generation Core™ i7/i5/i3 Pentium® Processor

Features

  • Intel® 2nd/3rd Generation Core™ i7/ i5/ i3 Processors
  • Intel® B75
  • DDR3 1600/1333/1066 MHz DIMM x 4, Max. 32GB
  • Dual/Three Independent Display: VGA, HDMI x 3
  • Gigabit Ethernet x 2
  • Onboard TPM Infineon SLB9635 TT 1.2
  • SATA 6.0Gb/s x 1, SATA 3.0Gb/s x 4
  • USB3.0 x 4, USB2.0 x 6

IMBM-Q87A

Micro ATX Industrial Motherboard with Intel® 4th Generation LGA1150 Processor, SATA3 x 5, Multiple Display Ports, Support iAMT 9.0

Features

  • Intel® 4th Generation Core™ i7/i5/i3 22nm LGA 1150 Socket Processor
  • Three/Dual Independent Display: VGA, DVI-D, DP x 2
  • Dual Gigabit Ethernet, LAN1 Supports iAMT 9.0
  • SATA 6.0 Gb/s x 5, USB 3.0 x 4, USB 2.0 x 8
  • Rich Expansion Slot: PCI-E【x16】 x 1, PCI-E 【x4】 x 1, PCI x 2, Mini-Card (or optional mSATA) x 1
  • TPM Support

IMBM-Q170A

6th Gen. Intel® Core™ Processor Micro ATX Board Support DDR4 DRAM, USB x 14 & iAMT Support

Features

  • 6th Gen. Intel® Core™ LGA1151 Processor
  • DDR4 DRAM Support, 2133 MHz, Max. 64GB
  • Three Independent Display: HDMI x 2, DVI-I Port x 1
  • Dual Intel® Gigabit Ethernet, iAMT Support
  • USB 3.0 Port x 10, USB 2.0 Port x 4
  • TPM Optional (Via Pin Header)

IMBM-H81B

Micro-ATX with Intel® 4th Generation Core™ Processor, DDR3 DRAM, USB x 14

Features

  • 4th Gen. Intel® Core™ LGA1150 Processor
  • DDR3 DRAM Support, 1600MHz, Max. 16GB
  • Two Independent Display: VGA x 1, DVI-I Port x 1
  • Realtek 8111G, Gigabit Ethernet x 2
  • USB 3.0 Port x 6, USB 2.0 Port x 8
  • COM Port x 10 (RS-232 x 9, RS-232/422/485 x 1)

EMB-KB1

Mini-ITX Embedded Motherboard with AMD 1st Generation APU SoC Processor, USB x 8 and SATA 3 x 2

Features

  • AMD 1st Generation APU SoC Processor
  • DDR3 1600MHz SODIMM x 2, Up to 16GB
  • Realtek 8111F, Gigabit Ethernet x 2
  • Dual Independent Display: VGA, DVI-D, LVDS
  • USB3.0 x 2, USB2.0 x 6, and SATA 6.0 Gb/s x 2
  • Rich Expansion: PCI-E〔x4〕 x 1, Mini Card x 2

EMB-LN8T

Mini-ITX Embedded Motherboard with Intel® Atom™ N455/D525 Processor

Features

  • Intel® Atom™ N455/D525 Processor
  • Intel® ICH8M
  • 204-pins SODIMM x 1 DDR3 800 Up To 4GB (Optional for 2nd SODIMM)
  • 10/100/1000Base-TX (RTL8111E)
  • 18-bit LVDS Or 24-bit LVDS
  • Speaker-out With 2W Amplifier
  • SATA 3.0Gb/s x 3, RAID 0 & 1
  • COM x 6 (RS-232 x 4, RS-232/422/485 x 2)
  • Mini Card x 1 (Optional For 2nd Mini Card with SIM)
  • Optional TPM1.2
  • DC 12V
  • Extra Slim With Height Only 20mm (Without Cooler, Dimm 2)

EMB-QM77

Embedded Motherboard with Intel® 3rd Generation Core™ i7/i5/Celeron® Quad Core/Dual Core Processor

Features

  • Socket rPGA988, Intel® 3rd Generation Core i7/i5/ Celeron Processor
  • Intel® Core™ i7/i5 + QM77
  • 204-pin Dual-channel DDR3 1066/1333/1600 MHz SODIMM x 2, Up to 16 GB
  • Gigabit Ethernet x 2
  • Dual Display Version: CRT, Dual 24-bit LVDS, DVI-D, HDMI, DisplayPort
  • Three Display Version: CRT, Dual 24-bit LVDS, DVI-D, DisplayPort x 2 (Optional)
  • SATA 6.0Gb/s x 2, SATA 3.0Gb/s x 2, Support RAID 0,1,5,10
  • USB2.0 x 6, USB3.0 x 4, COM x 2
  • PCI-E〔x16〕 x 1, Mini-Card x 1, CFast™ x 1, TPM x 1

EMB-B75B

Mini-ITX Embedded Motherboard with Intel® 2nd/3rd Generation Core™ i7/i5/i3 Processor

Features

  • Intel® Socket 1155 for 2nd/3rd Generation Core™ i7/i5/i3 Processor
  • Intel® B75 Express Chipset
  • DDR3 1600/1333MHz DIMM x 2, Up to 16GB
  • Dual Independent Display: VGA, LVDS, HDMI (Dual HDMI Optional)
  • Realtek RTL8111F, Gigabit Ethernet x 1
  • SATA 6.0 Gb/s x 1, USB3.0 x 2, PCI-E 3.0/2.0 〔x16〕x 1

IMBI-QM57

Embedded Motherboard with Intel® Core™ i7/i5 Mobile Processor

Features

  • Intel® Core™ i7/i5 rPGA988 (32/45nm) Processor Integrated Graphics & Memory Controller
  • Intel® QM57
  • Dual-Channel DDR3 800/1066 Memory (Up To 8 GB)
  • Intel® Gigabit Ethernet x 2, Support Intel iAMT 6.0
  • Dual View With VGA, DVI, HDMI, LVDS
  • SATA 3.0 Gb/s x 3, RAID 0, 1, 5, 10
  • USB2.0 x 8, COM x 4
  • PCI-Express [x4] x 1, Mini PCIe x 1, PCI x 1

EMB-H61B

Mini-ITX Embedded Motherboard with Intel® 2nd/3rd Generation Core™ i7/i5/i3 Processor

Features

  • Intel® Socket 1155 for 2nd/3rd Generation Core™ Processor up to 65W
  • Intel® H61 Express Chipset
  • DDR3 1066/1333 MHz SODIMM x 2, Up to 16GB
  • VGA, HDMI x 2 , LVDS Dual independent Display
  • Realtek 8111F x 2, Gigabit Ethernet x 2
  • PCI-E〔x4〕x 1, Full size Mini-Card x 1 (mSATA Optional) + SIM Card x 1
  • TPM Infineon SLB9635 TT 1.2

EMB-H61A

Mini-ITX Embedded Motherboard with Intel® 2nd/3rd Generation Core™ i7/i5/i3/Pentium® Processor

Features

  • Intel® Socket 1155 for 2nd/3rd Generation Core™ I7/i5/i3 Processor Up to 65W
  • Intel® H61
  • Dual-Channel DDR3 1333/1066 MHz SODIMM x 2, Up to 16 GB
  • Gigabit Ethernet x 2
  • Intel® Integrated Graphics Engine Supports Dual Display By VGA, DVI, HDMI, LVDS
  • HD 5.1CH Audio
  • SATA 3.0Gb/s x 2
  • USB2.0 x 8 , COM x 6
  • PCI-Express〔x4〕x 1, Mini-Card x 1 (mSATA optional), TPM

EMB-QM67

Embedded Motherboard with Socket G2 (rPGA988B) 2nd Generation for Intel® Core™ i7/i5/Celeron® QC/ DC Processor

Features

  • Socket G2 (rPGA988B) 2nd Generation Intel Core i7/ i5/Celeron QC/ DC Processor
  • Intel® QM67
  • 204-pin Dual-Channel DDR3 1066/1333/1600 MHz SODIMM x 2, Up to 16 GB
  • Gigabit Ethernet x 2
  • Intel® Integrated Graphics Engine Supports Dual View by VGA, DVI, HDMI, 24-bit Dual-Channel LVDS
  • HD Audio
  • SATA 3.0Gb/s x 2, Support RAID 0,1,5,10
  • USB2.0 x 8, COM x 6
  • PCI-Express〔x4〕x 1, Mini-PCIe x 1, CFast x 1, TPM x 1 (Optional)

EMB-BT7

Thin Mini-ITX Embedded Motherboard with Intel® Atom™ E3845 Processor, SATA3 x 2, SATA2 x 1, USB x 8

Features

  • Intel® Atom™ E3845 Processor
  • ECC SODIMM x 2, up to 8GB
  • Dual Displays: LVDS x 1, VGA x 1, HDMI x 1,
  • SATA 6.0 Gb/s x 1, SATA 3.0 Gb/s x 2
  • USB 3.0 x 1, USB 2.0 x 7
  • Full-size Mini-Card x 1 + SIM Card (mSATA default) x 1, Half-size Mini-Card (PCIe + USB)x 1

EMB-BT4

Thin Mini-ITX Embedded Motherboard with Intel® Atom™ J1900/N2807 Processor, SATA 6.0 Gb/s x 2, SATA 3.0 Gb/s x 2, USB x 8

Features

  • Intel® Atom™ J1900/N2807 Processor
  • DDR3 1333 MHz SODIMM x 2, Up to 8 GB, (J1900); DDR3 1333 MHz SODIMM x 1, Up to 4 GB, (N2807)
  • Dual Displays: LVDS x 1, VGA x 1, HDMI x 1
  • SATA 6.0 Gb/s x 2, SATA 3.0 Gb/s x 2
  • USB 3.0 x 1, USB 2.0 x 7
  • Full-size Mini-Card + SIM Card (mSATA Default) x 1, Half-size Mini-Card x 1
  • 12VDC

EMB-B75A

Mini-ITX Embedded Motherboard with Intel® 2nd/3rd Generation Core™ i7/i5/i3 Processor

Features

  • Intel® 2nd/3rd Generation Core™ i7/ i5/ i3 Processor
  • Intel® B75 Express Chipset
  • DDR3 1600/1333 MHz DIMM x 2, Up to 16GB
  • Dual/Three Independent Display: VGA, HDMI x 3
  • Gigabit Ethernet x 2
  • Onboard TPM Infineon SLB9635 TT 1.2
  • USB3.0 and SATA 6.0 Gb/s

EMB-H81B

Thin Mini-ITX Embedded Motherboard with Intel® 4th Generation Core™ i Series Processor

Features

  • Intel® 4th Generation Core™ i Series 22nm Processor
  • Intel® H81
  • DDR3 1333/1600 MHz SODIMM x 2, Up to 16 GB
  • Dual Independent Display: LVDS, VGA, HDMI, DP
  • SATA 6.0 Gb/s x 2, SATA 3.0 Gb/s x 1
  • USB 3.0 x 2, USB 2.0 x 6
  • PCI-E2.0〔x1〕x 1, Full-size Mini-Card (mSATA) x 1, Half-size Mini-Card x 1
  • DC 12~24V
  • Low Profile

EMB-BT2

Thin Mini-ITX Embedded Motherboard with Intel® Atom™ J1900 Processor, SATA2 x 1, USB2.0 x 10, Dual LVDS

Features

  • Intel® Celeron® J1900 Processor
  • Realtek 8111G, Gigabit Ethernet x 2
  • Dual Displays: VGA + LVDS, Dual LVDS
  • SATA 3.0Gb/s x 1
  • USB 2.0 x 10
  • Full-size Mini-Card with mSATA x 1, PCI-E〔x1〕x 1
  • ATX Power

EMB-QM87A

Embedded Motherboard with Onboard Intel® 4th Generation BGA 1364 Processor & iAMT Support

Features

  • Onboard Intel® 4th Generation BGA 1364 Processor
  • 204-pin DDR3L 1600/1333MHz SDRAM x 2, Up to 16 GB
  • HDMI x 3, VGA, 24-bit Dual-Channel LVDS
  • Audio Jack x 3 with BTX Type (Mic-in, Line-in, Line-out)
  • LAN 1 : Intel® I217-LM Gigabit Ethernet; LAN 2 : Realtek RTL 8111E Gigabit Ethernet; iAMT Support
  • SATA 6.0Gb/s x 4, SATA 3.0Gb/s x 2, Support RAID 0,1,5,10
  • PCI-E〔x16〕 x 1, Mini-PCIe x 1, COM x 5

EMB-BT1

Thin Mini-ITX Embedded Motherboard with Intel® Atom™ J1900/N2807/E3845/E3825 Processor, SATA3 x 2, SATA2 x 1, USB x 8

Features

  • Intel® Celeron® J1900/N2807/Atom™ E3845/E3825 Processor
  • Dual Displays: VGA x 1, HDMI x 1, LVDS x 1
  • Realtek 8111G, Gigabit Ethernet x 2
  • SATA 6.0Gb/s x 2, SATA 3.0Gb/s x 1
  • USB 3.0 x 1, USB 2.0 x 7
  • Full-size Mini Card with mSATA x 1, Half-size Mini Card x 1, PCI-E〔x1〕 x 1
  • 12V DC Power

EMB-H81A

Mini-ITX Embedded Controller with LGA 1150 socket for Intel® 4th Generation Core™ i Series Processor

Features

  • LGA 1150 Socket for Intel 4th Generation Core i Series Processor
  • Dual Independent Display: VGA, DVI-I, LVDS
  • Gigabit Ethernet x 2
  • SATA 6.0Gb/s x 2
  • USB 3.0 x 2, USB 2.0 x 7
  • PCI-E2.0 (x4) x 1, Full-size Mini Card (PCI-E + USB) with mSATA (Optional) x 1

EMB-Q87B

Intel® 4th Gen Core™ i Series Processor with 12V, 15~24V Wide Power Input Range

Features

  • Intel® 4th Generation Core™ i Series 22nm Processor
  • DDR3 1333/1600 MHz SODIMM x 2, Up to 16 GB
  • Three independent Display: DP x 3, VGA
  • SATA 6.0 Gb/s x 4
  • USB 3.0 x 4, USB 2.0 x 8
  • Full-size Mini-Card with Optional mSATA x 1, Half-size Mini-Card with Optional mSATA x 1
  • DC 12V, 15~24V

EMB-Q87A

Thin Mini-ITX Embedded Motherboard with Intel® 4th Generation Core™ i Series Processor, 12~24VDC Wide Power Input Range

Features

  • LGA 1150 Socket For Intel® 4th Generation Core™ i Series 22nm Processor
  • Intel® Q87
  • DDR3 1333/1600 MHz SODIMM x 2, Up to 16GB
  • Three Independent Display: LVDS, VGA, HDMI, DP
  • SATA 6.0Gb/s x 4
  • USB 3.0 x 4, USB 2.0 x 6
  • PCI-E2.0〔x4〕x 1, Full-size Mini-Card with Optional mSATA x 1, Half-size Mini-Card x 1
  • DC 12V, 15~24V

EMB-BSW1

Thin Mini-ITX Embedded Motherboard with Intel® N3710/N3060 Processor, SATA 6.0 Gb/s x 3, USB x 6 (up to 10)

Features

  • Intel® Atom™ N3710/N3060 Processor
  • DDR3L 1333/1600 MHz SODIMM x 2, Up to 8 GB
  • Three Independent Display: LVDS x 1, HDMI x 2, eDP x 1
  • SATA 6.0 Gb/s x 3
  • USB 3.0 x 4, USB 2.0 x 2 (up to 6)
  • Half-size Mini-Card (PCIe + USB) x 1, Full-size Mini-Card (mSATA default) (PCIe + USB optional) x 1
  • 12-24V DC
  • Low Profile

EMB-Q170C

Intel® 6th Generation Core™ i Series, LGA1151 Socket Processor, Max. 65W TDPs, M.2 x 1, SATA 6.0 Gb/s x 6

Features

  • Intel® Skylake-S LGA 1151 socket Processor, Max. 65W TDPs
  • DDR4 SO-DIMM x 2, Up to 32GB
  • Three independent Display : VGA x 1, HDMI x 2
  • SATA 6.0Gb/s x 6, M.2 E-key 2230 for PCIe
  • PCIe〔x8〕x 1
  • ATX power

EMB-Q170B

Mini-ITX, LGA1151 Socket For 6th Gen. Intel® Core™ i Series Processor, Up to 65W TDPs

Features

  • LGA1151 Socket For 6th Gen. Intel® Core™ i Series Processor
  • DDR4 SODIMM x 2, Up to 32GB
  • Three independent Display: eDP x 1, LVDS x 1, Combo Connector x 1, eDP/LVDS x 1, DP x 1
  • Intel LAN 219LM for vPro x 1, 211AT x 1
  • M.2 slot(E-key) x 1@top side, (M-key) x 1@bottom side
  • PCI-Express〔x4〕 x 1
  • Low Profile

EMB-Q170A

Mini-ITX, LGA1151 Socket For 6th Gen. Intel® Core™ i Series Processor, Up to 65W TDPs

Features

  • LGA1151 Socket For 6th Gen. Intel® Core™ i Series Processor
  • DDR4 SODIMM x 2, Up to 32 GB
  • Three Independent Display: DP x 3, VGA x 1
  • Intel® LAN 211AT x 1, LAN 219LM for vPro x 1
  • SATA 6.0 Gb/s x 2, M.2 slot (M-key) x 1
  • PCI-Express〔x16〕 (Gen3) x 1
  • ATX Power
  • 4K for Display Port

EMB-H110B

Mini-ITX, LGA1151 Socket For 6th Gen. Intel® Core™ i Series Processor, Up to 65W TDPs

Features

  • LGA1151 Socket For 6th Gen. Intel® Core™ i Series Processor
  • DDR4 SODIMM x 2, Up to 32GB
  • Two Independent Display: DP colay HDMI x 1, LVDS x 1, eDP x 1
  • SATA 6.0Gb/s x 2, Half-size Mini-Card x 1, Full/Half-size Mini-Card x 1
  • PCI-Express〔x1〕x 1
  • 12V DC
  • Low Profile

EMB-APL1

Mini-ITX Embedded Motherboard with Intel® N3350(DC)/N4200(QC) Processor

Features

  • DDR3L 1333/1600/1867 MHz SODIMM x 2, Up to 8 GB
  • Three Independent Display: VGA x 1, HDMI x 1, LVDS/eDP x 1
  • Realtek 8111G, Gigabit Ethernet x 2
  • COM Port x 6 (RS-232 x 5, RS-232/422/485 x 1)
  • Onboard TPM2.0 Optional
  • 12~24 Wide Range Voltage Power Input
  • Low Profile
  • PCIe〔x1〕 x 1, M.2 x 2

NITX-BD1

Intel® 5th Gen processor Nano-ITX Board With 2 DP, 1 LVDS and 7 USB port

Features

  • Intel® 5th Generation ULT 15W Processor
  • Three Independent Display: Display Port x 2, LVDS Port x 1 (Optional)
  • Dual Gigabit Ethernet
  • USB 3.0 Port x 4, USB 2.0 Port x 3
  • Mini-PCIe Slot x 1, M.2 Slot x 1

PFM-CVS Rev. B

PFM-CVS Rev.B

Features

  • Intel® Atom™ N2600 Dual Core 1.6GHz Processor
  • Intel® Atom™ N2600 + NM10
  • 204-pin DDR3 800/1066MHz SODIMM x 1, Up to 2GB
  • 10/100/1000Base-TX Ethernet x 1
  • CRT, 18-bit Single Channel LVDS LCD
  • 2CH HD Audio
  • SATA 3.0Gb/s x 1
  • USB2.0 x 4, COM x 4
  • PC/104+ Slot, Full-Size mSATA x 1/ Mini Card (Optional)
  • +12V Only Operation
  • AAEON Hi-Safe SDK/Utility Supported

PFM-CVS Rev. A

PFM-CVS, PC/104+ Module with Intel® Atom™ N2600 Processor

Features

  • Intel® Atom™ N2600 Dual Core 1.6GHz Processor
  • Intel® Atom™ N2600 + NM10
  • 204-pin DDR3 800/1066MHz SODIMM x 1, Max. 2GB
  • 10/100/1000Base-TX Ethernet x 1
  • CRT, 18-bit Single Channel LVDS LCD
  • SATA 3.0Gb/s x 1
  • USB2.0 x 4, COM x 4
  • PC/104+ Slot, Half-Size mSATA x 1/ Mini Card (Optional)
  • +12V Only Operation
  • AAEON Hi-Safe SDK/Utility Supported

GENE-LN05 Rev. B

3.5″ SubCompact Board With Intel® Atom™ N455/ D525 Processor

Features

  • Intel® Atom™ N455/D525 Processor
  • Intel® ICH8M
  • DDR3 800 SODIMM, Max. 4 GB For Intel® Atom™ D525; DDR3 800 SODIMM, Max. 2 GB For Intel® Atom™ N455
  • Gigabit Ethernet x 2, RJ-45 x 2
  • CRT, 18/24-bit Single Channel LVDS LCD
  • 2CH HD Audio
  • SATA 3.0Gb/s x 2 (Optional RAID 0 & 1), CompactFlash™ x 1
  • USB2.0 x 7, COM x 6, Parallel x 1, 8-bit Digital I/O
  • Onboard 4/5/8-wire Resistive Touch Screen Controller
  • Mini Card x 1
  • +12V or +5V (Optional)
  • Onboard Trusted Platform Module (Optional)

GENE-CV05

3.5″ SubCompact Board With Intel® Atom™D2550/N2800/N2600 Processor

Features

  • Intel® Atom™ D2550/ N2800/N2600 Processor
  • Intel® NM10
  • DDR3 800/1066 SODIMM, Max. 4 GB for Intel® Atom™ D2550/N2800 and Max. 2 GB For Intel® Atom™ N2600
  • Gigabit Ethernet x 2, RJ-45 x 2
  • CRT, DVI, 18/24-bit Single Channel LVDS LCD + 18/24-bit Dual-Channel LVDS LCD For Intel® Atom™ D2550; CRT, DVI, 18-bit Single Channel LVDS LCD + 18/24-bit Dual-Channel LVDS LCD For Intel® Atom™ N2800/N2600
  • 2CH HD Audio + 2W Amplifier
  • SATA 3.0Gb/s x 1, CFast™ x 1
  • USB2.0 x 6, COM x 6, 8-Bit Digital I/O, Parallel x 1 (Optional)
  • Onboard 4/5/8-wire Resistive Touch Screen Controller
  • Mini Card x 1
  • +12V Only Operation
  • Onboard Trusted Platform Module (Optional)
  • mSATA x 1 (Optional, Would Replace Mini Card Interface)
  • AAEON Hi-Safe SDK/Utility Supported

GENE-5315 Rev. B

3.5″ SubCompact Board With AMD Geode™ LX Series Processor

Features

  • Onboard AMD Geode™ LX800 Processor
  • AMD Geode™ LX + CS5536
  • DDR 333 MHz SODIMM x 1, Up to 1 GB or DDR 400 MHz SODIMM x 1, Up to 512 MB
  • 10/100Base-TX Ethernet x 2, RJ-45 x 2
  • Up to 24-bit Single Channel LVDS/ TTL LCD & CRT
  • AC97 Codec 2CH Audio
  • EIDE x 1, Floppy Disk Drive x 1, CompactFlash™ x 1
  • COM x 5, Parallel x 1, USB2.0 x 4, 8-bit Digital I/O
  • Mini-PCI x 1
  • +5V Only Operation

COM-QM77 Rev. B

COM Express Type 6 CPU Module with Onboard Intel® Core™ i7/i5/i3/Celeron Processor

Features

  • Onboard Intel® Core™ i7/ i5/ i3/ Celeron Processor (FCBGA1023)
  • Intel® QM77/HM76 PCH
  • Dual-channel SODIMM DDR3 1333/1600 Memory, Max. 16 GB
  • Gigabit Ethernet (iAMT 8.0 Support)
  • CRT, Up to 24-bit Dual-channel LVDS LCD, DisplayPort
  • SATA 6.0Gb/s x 2 + SATA 3.0Gb/s x 2
  • USB3.0 x 4, USB2.0 x 8
  • PCI-Express〔x16〕x 1, PCI-Express〔x1〕x 7
  • COM Express Basic Module, Pin-out Type 6, COM.0 Rev. 2.0

COM-CV Rev. B

COM Express Type 6 CPU Module with Onboard Intel® Atom™ D2550/N2600 Processor

Features

  • Onboard Intel® Atom™ D2550/N2600 Processor
  • Intel® NM10
  • SODIMM DDR3 1066 Memory, Max. 4 GB
  • Intel® 82583V Gigabit Ethernet
  • CRT, Up to 24-bit Dual-Channel LVDS, LCD, HDMI
  • SATA 3.0Gb/s x 2, USB3.0 x 2, USB2.0 x 8
  • PCI-Express 〔x1〕 x 4
  • COM Express Compact Module, 95mm x 95mm, Pin-out Type 6, COM.0 Rev. 2.0
  • -40°C ~ 85°C Wide Temperature Range Available for Selected Model

PICO-BT01

PICO-ITX Board with Intel® Atom™ or Celeron® SOC Series Processor

Features

  • Onboard Intel® Atom™ N2930/N2807/E3825 SOC Processor
  • DDR3L 1066/1333MHz SoDIMM x 1, Up to 8GB
  • 18/24-bit LVDS, CRT Co-lay Display Port
  • SATAII 3.0Gb/s x 1
  • USB3.0 x 1, USB2.0 x 2
  • Gigabit Ethernet x 1, RJ-45 x 1
  • RS-232 x 1, RS-232/422/485 x 1
  • mSATA/Mini Card x 1, Mini Card x 1
  • 4-bit Digital I/O
  • BIO Connector for Daughter Board

GENE-BT05

3.5” SubCompact Board with Intel® Atom™ and Celeron® Processor SoC

Features

  • Onboard Intel® Atom™ and Celeron® Processor SoC
  • DDR3L 1066/1333MHz SODIMM x 1, Up to 8 GB
  • Gigabit Ethernet x 2, RJ-45 x 2
  • CRT, 18/24-bit Dual-Channel LVDS LCD, HDMI
  • 2CH HD Audio
  • SATA 3.0Gb/s x 1, CFast™ x 1
  • USB3.0 x 1, USB2.0 x 3, COM x 4, 8-bit Digital I/O
  • Mini Card x 2 (Full-size x 1, Half-size x 1)
  • +12V Only Operation
  • Onboard 4/5/8-wire Resistive Touch Screen Controller (Optional)
  • AAEON Hi-Safe/SDK/Utility Supported
  • mSATA x 1 (Optional, Would Replace Mini Card Interface)
  • Onboard Trusted Platform Module (Optional)

EPIC-BDU7

EPIC Board with 5th Generation Intel® Core™ i3/i5/i7 ULT Processor SoC

Features

  • Onboard 5th Generation Intel® Core™ i Series ULT Processor SoC
  • DDR3L 1600 MHz SODIMM x 1, Up to 8 GB
  • Gigabit Ethernet x 2, RJ-45 x 2
  • VGA, LVDS, DP, LVDS (Optional), eDP (Optional)
  • SATA 6.0 Gb/s x 2, mSATA/Mini-Card x 1
  • USB 3.0 x 2 , USB 2.0 x 4
  • RS-232 x 4, RS-232/422/485 x 2
  • Optional Touch Screen, TPM and PCI-104
  • Mini-Card x 1, SIM x 1 (Optional)
  • 9-24V Operation
  • 15W TDP
  • SoC Solder up Design

GENE-1350

Features

  • TI OMAP 3503/3530 Processor
  • 3D Graphics & Video Accelerator Support with 3530 Processor
  • Onboard 128/256 MB (Optional) LP DDR RAM
  • 10/100Base-TX Ethernet
  • CRT/ 24-bit TTL LCD/ 18-bit LVDS LCD
  • 2CH Audio
  • Onboard NAND Flash, SD, MicroSD
  • USB2.0 Host x 2, USB2.0 Client x 1, COM x 2, 8-bit Digital I/O
  • Mini-Card x 2, Proprietary Expansion Slot x 1
  • Onboard 4-wire Resistive Touch Screen Controller
  • +9V To +24V DC Input
  • Onboard Battery Charger
  • Windows CE 6.0/ Linux 2.6.32/ Android 2.2
  • Less Than 3 Watt Power Consumption
  • Operating Temperature: W2: -40°C ~ 80°C, W1: -20°C ~ 70°C

PICO EZ Way

EmbCore introduce the PICO EZ WAY concept to address a broad range of challenges faced by a wide range of value-added resellers. By reducing the external chassis to two symmetrical parts, manufacturing only requires a singular tool. This reduces downtime, lowers maintenance, shortens lead time, improves time to market, and alleviates downstream pressure.

The “slot in, snap together” approach further reduces the total number of screws required, and enables their deployment in a structural reinforcement role. Additionally, this provides rapid access to all internal components, lowering costs and further enhancing ROI for customers.
Applications

  • Industry Automation
  • KIOSK
  • Ticket Machine
  • POS
  • Digital Signage

PICO-IMX6

Pico-ITX Fanless board with Freescale® ARM Cortex-A9 I.MX6 SoC

Features

  • Freescale® i.MX6 Quad Automotive/DualLite Commercial Processor
  • Onboard DDR3 Memory 1 GB
  • Gigabit Ethernet x 1
  • 18-bit Single-Channel LVDS, Mini HDMI
  • High Definition Audio Interface
  • SATA x 1, MicroSD Slot, eMMC (Optional, up to 16GB)
  • USB2.0 up to 4, USB OTG x 1, Mini-PCIe x 1, CANBus
  • +12V Power Input

PICO-HD01

Pico-ITX Fanless Board With HDMI and AMD G-Series T40E/T40R Processor

Features

  • Onboard AMD G-Series™ T40E/T40R Single/Dual Processor
  • AMD G-Series CPU + A50M
  • 204-pin SODIMM DDR3 1066MHz up to 4GB
  • Gigabit Ethernet x 1, RJ-45 x 1
  • CRT, 18-bit Single Channel LVDS, Mini HDMI
  • 2CH HD Audio
  • SATA 3.0Gb/s x 1, mSATA (Half-Size) Slot x 1 (Shared with Mini Card)
  • USB 2.0 x 5, COM x 2, 4-bit Digital I/O
  • +12V Operating

PICO-CV01

Pico-ITX Fanless Board With HDMI and Intel® Atom™ N2600 Processor

Features

  • Intel® Atom™ N2600 Processor up to 1.6 GHz
  • 204-pin SODIMM DDR3 800MHz Memory up to 2 GB
  • Gigabit Ethernet x 1, RJ-45 x 1
  • Mini HDMI Support
  • 18-bit Single Channel LVDS LCDs
  • HD Audio for Line-in/out & Mic
  • SATA 3.0Gb/s x 1, mSATA (Half-Size) Slot x 1 (Shared with Mini Card)
  • USB2.0 x 5, COM x 2, 4-bit Digital I/O
  • +12V Power Input

RICO-3288

Pico-ITX Fanless Board with HDMI and Rockchip ARM Cortex™-A17 Quad-core Processor

Features

  • Rockchip RK3288 ARM Cortex™-A17 Quad-core 1.6GHz
  • Onboard DDR3L Memory 2 GB
  • Onboard eMMC 16 GB
  • MicroSD Slot up to 64 GB
  • Gigabit Ethernet x 1
  • 18/24-bit Dual-Channel LVDS, eDP and HDMI
  • RS-232 x 1, RS-232/422/485 x 1
  • USB2.0 x 3, USB OTG x 1, Mini-PCIe x 1 (for 3G/4G module)
  • Optional 7.4V Battery Power Input
  • Optional high accuracy GPS module

PICO-APL1

Pico-ITX Board with Intel® Atom™/ Pentium® E3900 or N4200 Series Processor SoC

Features

  • Onboard Intel® ATOM/Pentium®/Celeron® E3900, N4200 Series
  • Processor SoC
  • DDR3L 1867Mhz SODIMM x 1, Up to 8 GB
  • 18/24-bit Dual Channel LVDS LCD
  • Support Triple Display (Optional)
  • HDMI Support 3840 x 2160 (4K x 2K)
  • SATA 3.0 x 1, mSATA (Full Size) x 1 or MiniCard x 1 (Optional)
  • Gigabit Ethernet x 1, RJ-45 x 1
  • USB3.0 x 2, USB2.0 x 1
  • RS-232 x 1, RS-232/422/485 x 1
  • Mini-Card x 1 (Half-Size)
  • Digital I/O 4-bit
  • BIO Connector for Daughter Board (Optional)

PICO-BSW1

Pico-ITX Board with Intel® Pentium®/Celeron® N3000 or X5-E8000 Series Processor SoC

Features

  • Onboard IntelR PentiumR/CeleronR N3000 or X5-E8000 Series Processor SoC
  • DDR3L 1600/1066 SODIMM x 1, Up to 8 GB
  • LVDS up to 48-bit (2CH)
  • Support Triple Display (Optional)
  • HDMI Up to 3840 x 2160 (4K) Resolution
  • SATA 3.0 x 1, mSATA (Full Size) x 1 or MiniCard x 1 (optional)
  • Gigabit Ethernet x 1, RJ-45 x 1
  • USB 3.0 x 2
  • RS-232 x 1, RS-232/422/485 x 1
  • Mini-Card x 1 (Half-Size)
  • Digital I/O 4-bit
  • BIO Connector for Daughter Board (Optional)

PICO-BT01

PICO-ITX Board with Intel® Atom™ or Celeron® SOC Series Processor

Features

  • Onboard Intel® Atom™ N2930/N2807/E3825 SOC Processor
  • DDR3L 1066/1333MHz SoDIMM x 1, Up to 8GB
  • 18/24-bit LVDS, CRT Co-lay Display Port
  • SATAII 3.0Gb/s x 1
  • USB3.0 x 1, USB2.0 x 2
  • Gigabit Ethernet x 1, RJ-45 x 1
  • RS-232 x 1, RS-232/422/485 x 1
  • mSATA/Mini Card x 1, Mini Card x 1
  • 4-bit Digital I/O
  • BIO Connector for Daughter Board

PCM-LN02

Board with Onboard Intel® Atom™ N455/D525 Processors

Features

  • Intel® Atom™ N455/D525 Processor
  • Intel® ICH8M
  • Onboard DDR3 667/800MHz, up to 2 GB
  • 10/100/1000Base-TX Ethernet x 2, RJ-45 x 2
  • Integrated Graphic Supports 18-bit or 24-bit LVDS Panel or TTL (Optional)
  • Speaker Out With 2W Amplifier (Wafer Box)
  • SATA 3.0 Gb/s x 2, CompactFlash™ x 1, EIDE x 1 (Optional)
  • USB2.0 x 6, RS-232 x 5, RS-232/422/485 x 1
  • PC/104+ (ISA+PCI), Mini-Card x 2 (1st: Full Size + SIM; 2nd: Half-size)
  • +12V Only Operation With Optional ATX
  • Optional TPM1.2

PCM-5895 Rev. B

Compact Board with AMD Geode™ LX Series Processor

Features

  • AMD Geode™ LX800 Processor
  • AMD Geode™ LX + CS5536
  • DDR 333/400 MHz DIMM x 1, Up to 1 GB or Onboard
  • DDR 333 Memory 256 MB
  • 10/100Base-TX Ethernet x 2, RJ-45 x 2
  • Up to 24-bit LVDS/TTL LCD, CRT
  • AC97 2CH Audio
  • Type 2 CompactFlash™ x 1, EIDE x 1
  • USB x 4, COM x 4, 8-bit Digital I/O x 1, Parallel x 1
  • PCI x 1, PC/104+ (Optional)
  • +5V Only Operation/ AT/ ATX
  • CAN Bus x 2 (Optional)

PCM-5895 Rev. A

Compact Board with AMD Geode™ LX Series Processor

Features

  • AMD Geode™ LX800 Processor
  • AMD Geode™ LX + CS5536
  • DDR 333/400 MHz DIMM x 1, Up To 1 GB
  • 10/100Base-TX Ethernet x 2, RJ-45 x 1, Pin Header x 1
  • Up To 24-bit LVDS/TTL LCD, CRT
  • AC97 2CH Audio
  • Type 2 CompactFlash™ x 1, EIDE x 1, Floppy Disk Drive x 1
  • USB x 4, COM x 4, 8-bit Digital I/O
  • PCI x 1, Mini-PCI, PC/104 x 1
  • +5V Only Operation/ ATX

PCM-QM77

Compact Board With Intel® 3rd Generation Core™ i7/i5/i3/Celeron® Mobile Processor

Features

  • Intel® 3rd Generation Core™ i Series i7/i5/i3/Celeron® PGA Processor
  • Intel 3rd Core i Series + QM77/HM76
  • 204-pin SODIMM DDR3 1333/1600MHz x 2 up to 16GB
  • Intel® 82579LM x 1/ Intel® 82583V x 1 10/100/1000Base-TX LANs, RJ-45 X 2
  • Up to 24-bit Dual Channel LVDS x 2, CRT, DVI
  • 2CH HD Audio
  • SATA 6.0Gb/s x 2, mSATA x 1, CFast™ x 1
  • USB 3.0 x 4, USB2.0 x 4, COM x 10, 16-bit Digital I/O
  • Mini Card x 1, PCI-104, Touch, TPM (Optional), PCI, PCI-E〔x16〕
  • AT/ATX Power Input
  • Supports iAMT8.0 and RAID 0,1 for QM77 Chipset
  • Supports AAEON Hi-Safe/Hi-Manager SDK & Utility

GENE-5315 Rev. B

3.5″ SubCompact Board With AMD Geode™ LX Series Processor

Features

  • Onboard AMD Geode™ LX800 Processor
  • AMD Geode™ LX + CS5536
  • DDR 333 MHz SODIMM x 1, Up to 1 GB or DDR 400 MHz SODIMM x 1, Up to 512 MB
  • 10/100Base-TX Ethernet x 2, RJ-45 x 2
  • Up to 24-bit Single Channel LVDS/ TTL LCD & CRT
  • AC97 Codec 2CH Audio
  • EIDE x 1, Floppy Disk Drive x 1, CompactFlash™ x 1
  • COM x 5, Parallel x 1, USB2.0 x 4, 8-bit Digital I/O
  • Mini-PCI x 1
  • +5V Only Operation

GENE-5315 Rev. A

3.5″ SubCompact Board With AMD Geode™ LX Series Processor

Features

  • Onboard AMD Geode LX800 Processor
  • AMD Geode LX + CS5536
  • SODIMM DDR333 Max. 1 GB, DDR400 Max. 512 MB
  • 10/100Base-TX Ethernet x 2, RJ-45 x 2
  • Up to 24-bit Single Channel LVDS/ TTL LCD & CRT
  • AC97 Codec 2CH Audio
  • EIDE x 1, Floppy Disk Drive x 1, CompactFlashTM x 1
  • COM x 2, Parallel x 1, USB2.0 x 4, 8-bit Digital I/O
  • Mini PCI And PC/104 Expansions
  • +5V Only Operation

GENE-CV05

3.5″ SubCompact Board With Intel® Atom™D2550/N2800/N2600 Processor

Features

  • Intel® Atom™ D2550/ N2800/N2600 Processor
  • Intel® NM10
  • DDR3 800/1066 SODIMM, Max. 4 GB for Intel® Atom™ D2550/N2800 and Max. 2 GB For Intel® Atom™ N2600
  • Gigabit Ethernet x 2, RJ-45 x 2
  • CRT, DVI, 18/24-bit Single Channel LVDS LCD + 18/24-bit Dual-Channel LVDS LCD For Intel® Atom™ D2550; CRT, DVI, 18-bit Single Channel LVDS LCD + 18/24-bit Dual-Channel LVDS LCD For Intel® Atom™ N2800/N2600
  • 2CH HD Audio + 2W Amplifier
  • SATA 3.0Gb/s x 1, CFast™ x 1
  • USB2.0 x 6, COM x 6, 8-Bit Digital I/O, Parallel x 1 (Optional)
  • Onboard 4/5/8-wire Resistive Touch Screen Controller
  • Mini Card x 1
  • +12V Only Operation
  • Onboard Trusted Platform Module (Optional)
  • mSATA x 1 (Optional, Would Replace Mini Card Interface)
  • AAEON Hi-Safe SDK/Utility Supported

GENE-LN05 Rev. B

3.5″ SubCompact Board With Intel® Atom™ N455/ D525 Processor

Features

  • Intel® Atom™ N455/D525 Processor
  • Intel® ICH8M
  • DDR3 800 SODIMM, Max. 4 GB For Intel® Atom™ D525; DDR3 800 SODIMM, Max. 2 GB For Intel® Atom™ N455
  • Gigabit Ethernet x 2, RJ-45 x 2
  • CRT, 18/24-bit Single Channel LVDS LCD
  • 2CH HD Audio
  • SATA 3.0Gb/s x 2 (Optional RAID 0 & 1), CompactFlash™ x 1
  • USB2.0 x 7, COM x 6, Parallel x 1, 8-bit Digital I/O
  • Onboard 4/5/8-wire Resistive Touch Screen Controller
  • Mini Card x 1
  • +12V or +5V (Optional)
  • Onboard Trusted Platform Module (Optional)

GENE-QM77 Rev. B

3.5″ SubCompact with Onboard Intel® Core™ i7-3555LE/ Celeron® 847E Processor

Features

  • Onboard Intel® Core™ i7-3555LE/ Celeron® 847E Processor
  • Intel QM77/HM76
  • SODIMM DDR3 1333/1600, Max. 8 GB
  • Gigabit Ethernet x 2, RJ-45 x 2
  • CRT or DVI (Optional), 18/24-bit Dual-Channel LVDS LCD x 2, HDMI
  • 2CH HD Audio
  • SATA 6.0Gb/s x 2 (Optional RAID), CFast™ x 1
  • USB3.0 x 2, USB2.0 x 6, COM x 4, 8-bit Digital I/O
  • Mini Card x 1
  • +12V Only Operation
  • Supports iAMT with Intel QM77
  • Onboard 4/5/8-wire Resistive Touch Screen Controller
  • AAEON Hi-Safe/Hi-Manager SDK/Utility Supported
  • mSATA x 1 (Optional, Would Replace Mini Card Interface)
  • IEEE 1588 Compatible

GENE-QM77 Rev. A

3.5” SubCompact Board with Intel® 3rd Generation Core™ i7/i5/i3 Mobile Processor

Features

  • Intel® 3rd Generation Core™ i7/i5/i3 Mobile Processor
  • Intel® QM77/HM76
  • DDR3 1333/1600 MHz SODIMM, Up to 8 GB
  • Gigabit Ethernet x 2, RJ-45 x 2
  • CRT, 18/24-bit Dual-Channel LVDS LCD x 2, DVI
  • 2CH HD Audio
  • SATA 6.0 Gb/s x 2 (Optional RAID), CFast™ x 1
  • USB3.0 x 2, USB2.0 x 6, COM x 4, 8-bit Digital I/O
  • Mini-Card x 1
  • +12V Only Operation
  • Supports iAMT with Intel® QM77
  • Onboard 4/5/8-wire Resistive Touch Screen Controller
  • AAEON Hi-Safe/Hi-Manager SDK/Utility Supported
  • mSATA x 1 (Optional, Would Replace Mini-Card Interface)
  • IEEE 1588 Compatible

GENE-A55E

3.5” SubCompact Board with AMD G-series T16R Processor

Features

  • AMD G-series T16R Single Core 615MHz Processor
  • AMD A55E
  • DDR3L SODIMM 1066 MHz Memory, Max. 4GB
  • VGA, 18/24-bit Dual Channel LVDS LCD
  • 2CH HD Audio
  • SATA 3.0Gb/s x 1 & CompactFlash™ x 1
  • PC/104 Interface Support
  • Gigabit Ethernet x 2
  • Support Digital I/O 8-bit, USB2.0 x 4, COM x 4, LPT x 1
  • Mini Card Slot x 1
  • +5V Input, AT/ATX

GENE-BT07

3.5” SubCompact Board with Intel® Celeron® J1900 Processor SoC

Features

  • Intel® Celeron® J1900 Processor SoC
  • DDR3L 1333 SODIMM Memory Max. up to 8GB
  • VGA, LVDS, eDP
  • 2 CH Audio, Support 8ohm/2W Speaker
  • 9 USB 2.0 , 6 COM
  • Mini-Card Slot x 1 (Full-size), mSATA x 1(Half-size)
  • DC 12V AT Mode Only

GENE-BT06

3.5” SubCompact Board with Intel® Atom™ and Celeron® SoC

Features

  • Intel® Atom™ E3845/ E3825 and Celeron® Processor SoC
  • Onboard Memory Max. 4 GB
  • CRT, 18/24-bit Dual-Channel LVDS LCD, HDMI (DP Co-lay with HDMI/CRT, Optional)
  • 2 CH Audio
  • SATA 3.0 Gb/s x 1 & mSATA (co-lay with Mini-Card)
  • Support 8-bit Digital I/O, USB2.0 x 3 , USB3.0 x 1
  • COM x 4 (RS-232 x 2, RS-232/422/485 x 2)
  • Mini-Card Slot x 2 (Full-size x 1, Half-size x 1)
  • Wide DC Support 9~24V
  • Supports TPM (Optional)
  • 4/5/8-wire Resistive Touch Screen Controller (Optional)
  • Solder Design For System Assembly and Thermal
  • Optional Accessories

GENE-BT05

3.5” SubCompact Board with Intel® Pentium & Celeron® N3000 Series Processor SoC

Features

  • Onboard Intel® Atom™ and Celeron® Processor SoC
  • DDR3L 1066/1333MHz SODIMM x 1, Up to 8 GB
  • Gigabit Ethernet x 2, RJ-45 x 2
  • CRT, 18/24-bit Dual-Channel LVDS LCD, HDMI
  • 2CH HD Audio
  • SATA 3.0Gb/s x 1, CFast™ x 1
  • USB3.0 x 1, USB2.0 x 3, COM x 4, 8-bit Digital I/O
  • Mini Card x 2 (Full-size x 1, Half-size x 1)
  • +12V Only Operation
  • Onboard 4/5/8-wire Resistive Touch Screen Controller (Optional)
  • AAEON Hi-Safe/SDK/Utility Supported
  • mSATA x 1 (Optional, Would Replace Mini Card Interface)
  • Onboard Trusted Platform Module (Optional)

GENE-BT04

3.5” SubCompact Board with Intel® Celeron® J1900/N2807 Processor SoC

Features

  • Intel® Celeron® J1900/ N2807 Processor
  • DDR3L 1333 SO-DIMM Slot x1, Max. up to 8GB
  • Intel® LAN i211AT x4 Gigabit Ethernet, RJ-45 x 4
  • HDMI x 2: HDMI 1 (w/Audio), HDMI 2 (w/o Audio)
  • USB 2.0 x 2, USB 3.0 x 1, COM x 1
  • Mini Card Slot x 1 (Full size, for USB only)
  • SATA 2.0 x 1
  • DC 12V ATX Mode

GENE-BSW5

3.5” SubCompact Board with Intel® Pentium & Celeron® N3000 Series Processor SoC

Features

  • Onboard Intel® Pentium® /Celeron® N3000 Series Processor SoC
  • DDR3L 1600/1066 SODIMM x 1, Up to 8 GB
  • Gigabit Ethernet x 2
  • Multiple Display in 18/24-bit 2CH LVDS, VGA, HDMI
  • AC97 2.3 Code 2CH Audio
  • Mini-Card x 2 (Full-Size x 1, Half-Size x 1)
  • mSATA x (optional, shared with Mini-Card interface)
  • USB3.0 x 4, RS-232 x 4, RS-232/422/485 x 2, Digital I/O 8-bit
  • +12V Only Operation

GENE-APL5

3.5” SubCompact Board with Intel® Pentium® N4200/ Celeron® N3350 Processor SoC

Features

  • Intel® Pentium® N4200/ Celeron® N3350 Processor SoC
  • DDR3L 1867 MHz SODIMM x 1, up to 8 G
  • VGA/LVDS/LVDS2 (HDMI Co-layout with LVDS2 Optional)
  • 2 CH Audio, SATA III x 1
  • Support 8-bit Digital I/O , USB 2.0 x 4 , USB 3.0 x 2 , COM x 4
  • Mini Card x 1 (Half size), mSATA x 1 (Full size)
  • DC 12V Only or +9~19V (Optional), AT/ATX Mode
  • Supports TPM (Optional)
  • 4/5/8-wire Resistive Touch Screen Controller (Optional)



GENE-SKU6

3.5” SubCompact Board with Intel® Core™ i7/i5/i3/Celeron® Processor SoC

Features

  • Intel® Core™ i7/i5/i3/Celeron® Processor SoC
  • DDR4 1866/2133, SODIMM x 1
  • DVI, CRT/DP, 18/24-bit Dual-Channel LVDS/
  • 2 CH Audio
  • SATA III x 1 & mSATA
  • Support 8-bit Digital I/O, USB 2.0 x 2 , USB 3.0 x 4
  • COM x 4 (RS-232 x 1, RS-232/422/485 x 3)
  • Mini-Card slot x 1 (Full size), TPM (Optional), SIM
  • Wide DC support 9~36V, +12V only (optional)
  • 4/5/8-wire resistive Touch Screen Controller
  • BIO Connector for Daughter Board
  • Solder Design for system assembly and thermal
  • Intel® Ethernet Controller I210 and I211-AT

Enquiry Form



    Mini-ITX Motherboards

    HomeEmbedded BoardsIndustrial MotherboardsMini-ITX Motherboards

    EMB-KB1

    • Enquiry Now
    • More Info

    EMB-LN8T

    • Enquiry Now
    • More Info

    EMB-QM77

    • Enquiry Now
    • More Info

    EMB-B75B

    • Enquiry Now
    • More Info

    IMBI-QM57

    • Enquiry Now
    • More Info

    EMB-H61B

    • Enquiry Now
    • More Info

    EMB-H61A

    • Enquiry Now
    • More Info

    EMB-QM67

    • Enquiry Now
    • More Info

    EMB-BT7

    • Enquiry Now
    • More Info

    EMB-BT4

    • Enquiry Now
    • More Info

    EMB-B75A

    • Enquiry Now
    • More Info

    EMB-H81B

    • Enquiry Now
    • More Info

    EMB-BT2

    • Enquiry Now
    • More Info

    EMB-QM87A

    • Enquiry Now
    • More Info

    EMB-BT1

    • Enquiry Now
    • More Info

    EMB-H81A

    • Enquiry Now
    • More Info

    EMB-Q87B

    • Enquiry Now
    • More Info

    EMB-Q87A

    • Enquiry Now
    • More Info

    EMB-BSW1

    • Enquiry Now
    • More Info

    EMB-Q170C

    • Enquiry Now
    • More Info

    EMB-Q170B

    • Enquiry Now
    • More Info

    EMB-Q170A

    • Enquiry Now
    • More Info

    EMB-H110B

    • Enquiry Now
    • More Info

    EMB-APL1

    • Enquiry Now
    • More Info

    Our Products

    • Embedded Boards
      • Embedded Single Board Computers
        • 3.5” SubCompact Boards
        • 5.25″ Compact Boards
        • Pico-ITX Boards
        • RISC-Based CPU Modules
        • Wide Temperature Boards
      • Industrial Motherboards
        • NANO-ITX Motherboards
        • Mini-ITX Motherboards
        • Micro-ATX Motherboards
        • ATX Motherboards
    • Network Appliance
      • Rackmount Network Appliance
      • Desktop Network Appliance
    • Panel PC
      • Panel PC for HMI
      • Wide-temp. HMI Panel PC
      • Modular HMI Panel PC
      • Stainless Panel PC
      • Multi-touch Panel PC for Infotainment
    • Industrial Touch Displays
      • Industrial Touch Display for Automation
      • Industrial Multi-touch Display for Infotainment
    • Railway Computers
    • Fanless Embedded Box PC
      • Entry-level Box PC
      • Ultra-slim Box PC
      • Automation Box PC
    • Iot Gateway Solutions
      • Gateway Boards
      • Gateway System

    Information

    • Home
    • About
    • Products
      • Embedded Boards
        • Embedded Single Board Computers
        • Industrial Motherboards
      • Network Appliance
        • Rackmount Network Appliance
        • Desktop Network Appliance
      • Panel PC
        • Panel PC for HMI
        • Wide-temp. HMI Panel PC
        • Modular HMI Panel PC
        • Stainless Panel PC
        • Multi-touch Panel PC for Infotainment
      • Industrial Touch Displays
        • Industrial Touch Display for Automation
        • Industrial Multi-touch Display for Infotainment
      • Railway Computers
      • Fanless Embedded Box PC
        • Automation Box PC
        • Ultra-slim Box PC
        • Entry-level Box PC
      • Iot Gateway Solutions
        • Gateway System
        • Gateway Boards
    • Applications
      • Food & Beverages
      • Transportation & Harbor
      • Network Appliance
      • Smart Community
      • Digital Signage
      • Entertainment & Gaming
      • Life Automation & Retail
      • Energy And Utilities
      • Data Centers
      • Government And Military
      • Intelligent Vending Machine
    • Career
    • Enquiry
    • Contact

    Products

    • Fanless Embedded Box PC
    • Embedded Boards
    • Network Appliance
    • Panel PC
    • Industrial Touch Displays
    • Railway Computers
    • Iot Gateway Solutions

    Get In Touch

    Unit No. 2, U.S. Complex, Mathura Road, Jasola, Opp. Apollo Hospital, New Delhi- 110 076

    • +91 11 2639 7182
    • info@embcoretech.co.in

    Copyright © 2017, All Rights Reserved.
    Web Design by Abacus Desk

    • Home
    • About
    • Products
      • Embedded Boards
        • Embedded Single Board Computers
        • Industrial Motherboards
      • Network Appliance
        • Rackmount Network Appliance
        • Desktop Network Appliance
      • Panel PC
        • Panel PC for HMI
        • Wide-temp. HMI Panel PC
        • Modular HMI Panel PC
        • Stainless Panel PC
        • Multi-touch Panel PC for Infotainment
      • Industrial Touch Displays
        • Industrial Touch Display for Automation
        • Industrial Multi-touch Display for Infotainment
      • Railway Computers
      • Fanless Embedded Box PC
        • Automation Box PC
        • Ultra-slim Box PC
        • Entry-level Box PC
      • Iot Gateway Solutions
        • Gateway System
        • Gateway Boards
    • Applications
      • Food & Beverages
      • Transportation & Harbor
      • Network Appliance
      • Smart Community
      • Digital Signage
      • Entertainment & Gaming
      • Life Automation & Retail
      • Energy And Utilities
      • Data Centers
      • Government And Military
      • Intelligent Vending Machine
    • Career
    • Enquiry
    • Contact
